Wurth Elektronik WR-MPC3 Series Straight Through Hole PCB Header, 2 Contacts, 3 mm Pitch, 1 Row, Shrouded MPC3

Wurth Elektronik MPC3 Straight Through Hole PCB Header, model MPC3, is a high-quality male connector designed for single row wire-to-board connections with a 3 mm pitch and 2 contacts.

This series utilizes a black PA9T liquid crystal polymer housing that meets UL94-V0 flammability standards, ensuring safety and durability in demanding industrial environments. The contacts are precision stamped from copper alloy and plated with tin, providing reliable electrical conductivity and resistance to corrosion.

Its through-hole mounting type and a tail pin length of 3.18 mm allow secure soldering onto printed circuit boards, while the shrouded design offers mechanical protection and prevents misalignment during mating.

With an operating voltage of 250V and current rating of 5A, this PCB header is suitable for a wide range of electronic applications including industrial automation, power supplies, telecommunications, and signal processing hardware.

The operating temperature range from -40°C to 105°C enables use in diverse environmental conditions, making it robust for commercial and industrial uses. The connector features a single row, 2 contact design with 3 mm pitch spacing.

Housing material is liquid crystal polymer with UL94-V0 black PA9T standard. Contact materials include copper alloy with tin plating for durability. Mounting is through hole with solder termination for secure placement. Suitable for wire-to-board connector systems with shrouded protection.

Supports continuous operation from -40°C up to 105°C temperature. Rated for 5A current and 250V voltage capacity. This Wurth MPC3 PCB header is a reliable component widely used in electronics manufacturing, automotive electronics, industrial machines, and communication equipment.
