JST PH Series Straight Surface PCB Header 5 Contacts 2 mm Pitch 1 Row Shrouded B5B-PH-SM4-TB(LF)(SN)

The JST B5B-PH-SM4-TB(LF)(SN) is a PH Series Straight Surface PCB Header designed for reliable wire-to-board connections in electronic assemblies. Featuring 5 contacts arranged in a single row with a 2 mm pitch, this connector is fully shrouded to enhance safety and prevent misalignment during installation.

Its polyamide housing and copper alloy contacts plated with tin ensure robust mechanical strength and corrosion resistance. The connector supports wire sizes ranging from 32 AWG to 24 AWG and uses solder termination for secure electrical connections. Rated for a continuous current of 2A and voltage up to 100V AC, it is suitable for a wide range of low-power electronic applications.

Designed for surface mount technology (SMT), this header includes a printed circuit board retention mechanism that facilitates reliable placement and soldering onto PCBs. The temperature operating range from -25°C to 85°C allows use in varied industrial environments including electronic manufacturing, telecommunications, consumer electronics, and instrumentation.

The connector's male contacts and straight orientation enable straightforward mating with corresponding wire-to-board connectors. Its compact and low insertion force design supports efficient assembly in complex electronic devices requiring high-density interconnections.

This product is backed by compliance with UL, CSA, and TUV certifications ensuring industry-standard safety and performance. It is an ideal choice for applications demanding compact, reliable, and cost-effective PCB header connectors.

Compact and fully shrouded design ensures safety and alignment. Polyamide housing and copper alloy contacts with tin plating enhance durability. Supports 5 contacts in a single row with 2 mm pitch spacing. Operates within temperature range from -25°C to 85°C suitable for diverse environments.

Rated for 2A current and 100V AC voltage for medium power applications. Solder termination type compatible with surface mount PCB assembly processes. Designed for wire sizes from 32 AWG to 24 AWG for flexibility. Includes PCB retention mechanism for reliable mounting during soldering.

Male contact gender and straight orientation facilitate mating with compatible connectors. UL, CSA, and TUV certified ensuring compliance with global standards.

This JST PH Series PCB Header connector is widely used in industrial, electronic manufacturing, telecommunications, instrumentation, and consumer electronics applications requiring robust and reliable wire-to-board connections.
