Wurth Elektronik WR-MPC3 Series Straight Through Hole PCB Header, 16 Contacts, 3 mm Pitch, 2 Row, Shrouded MPC3

Wurth Elektronik MPC3 is a 3.0 mm pitch vertical mount dual row male PCB header designed for reliable and efficient wire-to-board connections. This WR-MPC3 series features 16 contacts arranged in two rows with a shrouded black liquid crystal polymer housing, ensuring mechanical protection and alignment during mating with compatible female receptacles.

Manufactured with tin-plated copper alloy contacts, this PCB header supports a current rating of 5 amperes and a voltage rating of 250 volts, making it suitable for power and signal transmission in industrial, electronic, and power distribution systems.

The through-hole mounting type provides robust mechanical fixation to PCBs, enhancing durability in demanding environments. Operating reliably within a temperature range of -40°C to 105°C, it meets the needs of applications requiring stable performance under thermal stress.

Additional features include a tail pin length of 3.2 mm for secure soldering and compliance with no specific approvals but high-quality manufacturing standards typical of Wurth Elektronik components. The shrouded design prevents incorrect connector insertion, increasing service reliability.

This PCB header is ideal for industrial control equipment, power supply units, embedded systems, and other electronics assembly requiring dependable, compact male pin connectors. Features a 3 mm pitch for precise PCB mounting.

16 male contacts arranged in 2 rows for compact connectivity. Constructed with Liquid Crystal Polymer housing ensures durability. Supports a maximum current of 5 amperes for versatile applications. Contacts are tin-plated copper alloy for enhanced conductivity and corrosion resistance.

Designed with a shrouded housing to prevent misalignment during mating. Through hole mount type provides strong mechanical stability. Tail pin length is 3.2 mm for reliable solder connections. Operates reliably between -40°C and 105°C temperature range.

Rated for 250 volts suitable for various electronic and power applications.
