Wurth Elektronik 0.2μH 1206 Shielded Surface Mount Common Mode Line Filter with Ferrite Core, Dual Inductor 744232161

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 0.2μH 1206 Shielded Surface Mount Common Mode Line Filter with Ferrite Core, Dual Inductor 744232161

Name: Wurth Elektronik 0.2μH 1206 Shielded Surface Mount Common Mode Line Filter with Ferrite Core, Dual Inductor 744232161
Brand: Wurth Elektronik
SKU: 336647
Price: 1.26 USD
Availability: InStock



Category Ferrite Core Brand Wurth Elektronik Condition New

Specifications

Country of Origin	India
Brand	Wurth Elektronik
Height	1.8mm
Length	3.2mm
Depth	1.6mm
Packaging	Tape & Reel
Series	WE-CNSW SMD
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	0.2μH
Standards/Approvals	IEC 61249-2-21, JEDEC JS709B, REACH, RoHS
Package/Case	1206
Maximum DC Current	340mA
Pin Count	4
Maximum DC Resistance	400mΩ
Inductance Tolerance	±25 %
Termination Style	Surface Mount
Inductor Construction	Dual
Automotive Standard	AEC-Q200

Key Features

This common mode filter features a dual inductor construction for enhanced performance.
Designed for surface mount applications with a 1206 package size.
Maximum DC current rating is 340mA, suitable for low current circuits.
Inductance tolerance is ±25%, facilitating precise filtering capabilities.
Ferrite core material provides effective shielding and noise reduction.
Operating temperature range from -40°C to 125°C supports demanding environments.
Complies with automotive AEC-Q200 and industry standards IEC 61249-2-21, JEDEC JS709B, REACH, RoHS.
Recommended for high speed data lines such as USB 2.0, Firewire, LAN, and LVDS interfaces.

Product Description

Wurth Elektronik model 744232161 is a 0.2μH dual inductor, shielded surface mount common mode line filter constructed with a ferrite core. Its 1206 package size and surface mount termination style make it ideal for compact printed circuit board designs requiring high frequency noise suppression.

This component supports a maximum DC current of 340mA and exhibits an inductance tolerance of ±25%, ensuring reliable performance in filtering common mode noise. Operating temperature ranges from -40°C to 125°C, allowing use in a wide variety of industrial and automotive environments. The inductor's molded construction enhances durability, while its shielding helps minimize electromagnetic interference.

The filter complies with automotive-grade AEC-Q200 and meets RoHS, REACH, IEC, and JEDEC standards, confirming its suitability for stringent manufacturing requirements. The ferrite core material optimizes common mode noise suppression for high speed data applications including USB 2.0, Firewire, LVDS, and LAN lines.

This Wurth Elektronik common mode choke is recommended for electronics manufacturing, industrial machinery, automotive electronics, and communication equipment applications requiring efficient EMI noise reduction with surface mount design convenience.

This common mode filter features a dual inductor construction for enhanced performance. Designed for surface mount applications with a 1206 package size. Maximum DC current rating is 340mA, suitable for low current circuits.

Inductance tolerance is ±25%, facilitating precise filtering capabilities. Ferrite Core material provides effective shielding and noise reduction. Operating temperature range from -40°C to 125°C supports demanding environments.

Complies with automotive AEC-Q200 and industry standards IEC 61249-2-21, JEDEC JS709B, REACH, RoHS. Recommended for high speed data lines such as USB 2.0, Firewire, LAN, and LVDS interfaces. Explore more components in the Surface Mount Inductors category by Wurth Elektronik at EnvMart for your electronic project and manufacturing requirements.
