Bourns Shielded Coupled Inductor Ferrite Core 33 μH 3.28A 0.25V 12.5x12.5x6mm SRF1260-330M

Free Delivery in India | Lowest Global Shipping Charges

Bourns Shielded Coupled Inductor Ferrite Core 33 μH 3.28A 0.25V 12.5x12.5x6mm SRF1260-330M

Name: Bourns Shielded Coupled Inductor Ferrite Core 33 μH 3.28A 0.25V 12.5x12.5x6mm SRF1260-330M
Brand: BOURNS
SKU: 250402
Price: 1.38 USD
Availability: InStock



Category Ferrite Core Brand BOURNS Condition New

Specifications

Country of Origin	India
Voltage	0.25V
Brand	Bourns
Dimensions	12.5 x 12.5 x 6 mm
Height	6mm
Length	12.5mm
Model	SRF1260-330M
Depth	12.5mm
Current Rating	3.28A
Series	SRF1260
Maximum Operating Temperature	105°C
Tolerance	±20 %
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance Range	0.47 to 4000 μH
Inductance	33μH
Shielding	Shielded
Package/Case	1260
Inductor Construction	Shielded
Multiple applications	parallel, series

Key Features

Ferrite core construction ensures efficient magnetic performance.
Provides stable inductance of 33 μH with ±20% tolerance.
Rated for a current of 3.28A and voltage of 0.25V.
Compact dimensions of 12.5 x 12.5 x 6 mm for easy PCB integration.
Shielded design minimizes electromagnetic interference and radiation.
Operates reliably in temperature range from -40°C to 105°C.
Multiple applications including SEPIC topology and power supplies for communication equipment.
Suitable for use in notebooks, desktops, servers, LCDs, camcorders, and HDTVs.

Product Description

Bourns SRF1260-330M is a high-quality shielded coupled inductor featuring a ferrite core with an inductance of 33 μH. It is designed to provide stable performance with a tolerance of ±20% and a current rating of 3.28A, operating at a low voltage of 0.25V.

The compact size of 12.5 mm length and width with a height of 6 mm allows it to fit easily onto printed circuit boards used in advanced electronics equipment. The shielded construction reduces electromagnetic interference, making it well-suited for applications where magnetic noise must be minimized.

This inductor is rated for operation within a wide temperature range from -40°C to 105°C, ensuring reliability under various environmental conditions. It is applicable in multiple circuit topologies such as parallel, series, dual-inductor, and transformer configurations.

Ideal uses include power supplies for communication equipment, notebooks, desktop computers, servers, LCD and flat panel displays, backlights, camcorders, and HDTV systems. Ferrite Core material provides efficient magnetic properties.

Shielded construction minimizes electromagnetic emissions. Inductance range supports diverse circuit designs. Temperature range ensures durability in varied environments. Supports SEPIC topology and other power supply applications.

Suitable for consumer and professional electronic devices. Dimensions optimized for PCB mounting and assembly. Reliable current and voltage ratings for secure operation. Explore additional Bourns coupled inductors and related components in the Electronics & Electricals category on EnvMart for your industrial and manufacturing needs.
