Bourns Wirewound Surface Mount Inductor, Iron Core, 120μH ±10%, 5.8A, 2 Pins, 30.5mm Diameter, PM2120
Specifications
| Country of Origin | Honduras |
|---|---|
| Diameter | 30.5mm |
| Brand | Bourns |
| Height | 22.1mm |
| Length | 30.5mm |
| Model | PM2120 |
| Depth | 25.4mm |
| Packaging | 77 pieces per Box |
| Series | PM2120 |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Iron |
| Inductance | 120μH |
| Standards/Approvals | RoHS Directive 2002, RoHS Recast 2011, EU, EC, 95 |
| Package/Case | Surface Mount |
| Maximum DC Current | 5.8A |
| Pin Count | 2 |
| Maximum DC Resistance | 39mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- 120μH inductance delivers stable performance in demanding circuitry.
- 5.8A maximum DC current supports high power designs.
- ±10% inductance tolerance ensures consistent operation.
- Iron core enhances magnetic performance and reliability.
- Surface mount construction simplifies PCB assembly.
- 30.5mm diameter, 22.1mm height, and 25.4mm depth offers compact placement.
- Wirewound technology improves mechanical strength and efficiency.
- Operates between -55°C and 105°C, suitable for industrial environments.
Product Description
Bourns PM2120-121K-RC Wirewound Surface Mount Inductor is engineered for reliable performance in DC/DC converter input and output stages, as well as industrial electronics demanding robust current handling and magnetic stability. Featuring a toroidal Iron core, this inductor provides an inductance of 120μH with a tolerance of ±10% and supports maximum DC currents up to 5.8A.
Its wirewound structure ensures enhanced mechanical strength and improved thermal dissipation. Designed with a surface mount termination style, the PM2120-121K-RC enables efficient, space-saving integration onto printed circuit boards. The part incorporates two pins and offers dimensions of 30.5mm diameter, 22.1mm height, and 25.4mm depth, making it suitable for compact, high-performance electronic assemblies.
120μH inductance delivers stable performance in demanding circuitry. 5.8A maximum DC current supports high power designs. ±10% inductance tolerance ensures consistent operation. Iron core enhances magnetic performance and reliability.
Surface mount construction simplifies PCB assembly. 30.5mm diameter, 22.1mm height, and 25.4mm depth offers compact placement. Wirewound technology improves mechanical strength and efficiency. Operates between -55°C and 105°C, suitable for industrial environments.
RoHS compliant for worldwide electronic use.
The PM2120 series is RoHS compliant, aligning with global environmental standards and providing assurance for use in modern manufacturing. Its robust current rating, precision build, and reliable construction make it a preferred choice in industrial, electronics, power supply, and converter applications.
Typical use cases include input/output filtering in DC/DC converters, signal conditioning for precision analog circuits, and electromagnetic interference management in industrial control electronics.
Explore more Surface Mount Inductors from Bourns and discover high-quality passive components for demanding applications on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance of 120μH with a tolerance of ±10%.
The maximum DC current supported by this inductor is 5.8A.
It has a diameter of 30.5mm, a height of 22.1mm, and a depth of 25.4mm.
It operates within a temperature range of -55°C to 105°C.
The inductor is constructed with an iron core, enhancing its magnetic performance.
This unit features a surface mount termination style, facilitating efficient PCB assembly.
It has a pin count of 2.
It is compliant with the RoHS Directive 2002 and the RoHS Recast 2011, ensuring it meets global environmental standards.
It utilizes wirewound technology, which improves mechanical strength and efficiency.
This inductor is packaged with 77 pieces per box.
It is commonly used in DC/DC converter input/output stages and for signal conditioning in precision analog circuits.
The maximum DC resistance is 39mΩ.
