Bourns 0.11 A 230V Plastic Body Surface Mount Dual Resettable Fuse CMF-SDP35A-2
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 230V |
| Brand | Bourns |
| Body Material | Plastic |
| Height | 10.2mm |
| Length | 8.75mm |
| Model | CMF-SDP35A-2 |
| Width | 7.2mm |
| Series | CMF-SDP |
| Maximum Operating Temperature | 125°C |
| Package Type | Surface Mount Dual |
| Minimum Operating Temperature | -40°C |
| Trip Current | 230mA |
| Standards/Approvals | K.21, RoHS, ITU-T K.20 |
| Time to Trip | 0.04s |
| Hold Current | 0.11A |
| Maximum Resistance | 35Ω |
Key Features
- The fuse is designed with two resistance-matched PTCs in a plastic housing for reliable performance.
- It operates with a trip current of 230mA and a trip time of 0.04 seconds to protect circuits quickly.
- Suitable for surface mount technology and comes in a compact size of 8.75mm length, 10.2mm height, and 7.2mm width.
- Designed to withstand operating temperatures from -40°C to 125°C for durability in harsh environments.
- Provides maintenance-free automatic reset for thousands of cycles without fuseholder requirements.
- Commonly used in security systems, power supplies, automotive equipment, and telecommunications.
Product Description
Bourns CMF-SDP35A-2 is a surface mount dual resettable fuse designed to protect electrical and electronic circuits from excessive currents by transitioning from low resistance to high resistance state during overload or short circuit conditions. This resettable fuse has a hold current of 0.11 A, a trip current of 230mA, and operates at 230V with a rapid trip time of 0.04 seconds.
The fuse is housed in a plastic casing, measuring 8.75mm in length, 10.2mm in height, and 7.2mm in width, designed to accommodate surface mount dual mounting. It supports operating temperatures from -40°C to 125°C and has a maximum resistance of 35Ω. Its design offers narrow resistance tolerance and is RoHS compliant, meeting standards K.21 and ITU-T K.20.
This device is maintenance-free and can reset automatically thousands of times without requiring a fuseholder, making it ideal for compact and efficient circuit protection in various industrial and commercial applications.
Main applications include security systems, power supplies and transformers, automotive and medical equipment, instrumentation and control, computers and peripherals, and audio-visual and telecommunications equipment. Its robust design ensures reliable protection while enabling automatic reset after fault clearance, enhancing equipment uptime.
The fuse features two resistance-matched PTCs within a plastic housing for consistent performance. Narrow resistance tolerance ensures precise circuit protection. Maintenance-free automatic reset extends product life through multiple fault cycles.
Compact surface-mount design fits modern electronic assemblies. RoHS compliant with K.21 and ITU-T K.20 standards. Versatile industrial and commercial applications including security and automotive sectors.
Choose Bourns Resettable Fuses for reliable, efficient circuit protection solutions at EnvMart. Explore our extensive selection of electronic components and accessories to suit your technical needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The trip current of this model is 230mA, which allows it to protect circuits from excessive currents effectively.
This resettable fuse measures 8.75mm in length, 10.2mm in height, and 7.2mm in width, making it suitable for compact installations.
The maximum operating temperature for this unit is 125°C, allowing it to function in various demanding environments.
The hold current rating for this resettable fuse is 0.11 A, ensuring it can handle normal operating conditions without tripping.
It has a rapid trip time of 0.04 seconds, which helps to protect circuits quickly during overload conditions.
Yes, the Bourns CMF-SDP35A-2 is RoHS compliant and meets standards K.21 and ITU-T K.20, ensuring it adheres to environmental regulations.
This resettable fuse is designed for surface mount dual installation, making it compatible with modern electronic assemblies.
The fuse is housed in a plastic body, which provides a durable and lightweight solution for circuit protection.
The maximum resistance of the CMF-SDP35A-2 is 35Ω, which contributes to its narrow resistance tolerance for precise circuit protection.
This model is commonly used in security systems, power supplies, automotive equipment, and telecommunications, among other applications.
The minimum operating temperature for this resettable fuse is -40°C, allowing it to function in extreme cold conditions.
This unit features a maintenance-free automatic reset capability, allowing it to reset after fault clearance without the need for a fuseholder, enhancing equipment uptime.
