Wurth Elektronik Surface Mount Common Mode Line Filter 0805 Package 400mA Max DC Current Ferrite Core 744231061

Wurth Elektronik 744231061 is a Surface Mount Common Mode Line Filter in the 0805 package, designed for high-frequency EMI noise suppression in electronic applications. It features a ferrite core and dual coil construction, delivering effective filtering while maintaining minimal impact on high-speed signals.

This common mode choke supports a maximum DC current of 400mA and has an inductance tolerance of ±25%, providing reliable performance consistency. The compact size with length and depth of 2mm and 1.2mm height/depth respectively, makes it suitable for dense surface mount assemblies on PCBs.

The product supports operation in temperatures ranging from -40°C to 125°C and meets the AEC-Q200 automotive standard, making it ideal for automotive and industrial electronics environments requiring robust filtering solutions. The device is RoHS compliant, ensuring environmentally safe manufacturing practices.

The filter is supplied in tape & reel packaging to support automated pick-and-place assembly in manufacturing lines. Its primary applications include high-speed data lines such as USB 2.0, Firewire, LVDS, and LAN where common mode noise can interfere with signal integrity.

High common mode EMI noise suppression at elevated frequencies. Symmetrical winding construction for minimal signal disturbance. Ferrite Core material enhances magnetic properties for noise filtering. Broad temperature tolerance suitable for harsh conditions.

Compliant with environmental and automotive standards. Tape and reel packaging for production efficiency.
