Wurth Elektronik FPC Connector 0.5 mm Pitch 10 Way Horizontal Male Surface Mount 687110182122

Wurth Elektronik 687110182122 FPC Connector is a precision-engineered 10 way horizontal male connector designed for flexible printed circuit (FPC) applications. Featuring a fine 0.5 mm pitch, this surface mount connector facilitates compact and reliable electrical connections on printed circuit boards in industrial and commercial electronic assemblies.

The connector contacts are manufactured from high-quality phosphor bronze providing excellent electrical performance and mechanical strength. Contact surfaces are plated with tin over nickel to offer superior corrosion resistance and ensure long-term reliability even in challenging operating environments.

This FPC connector supports a zero insertion force (ZIF) mechanism, which minimizes wear and tear on the delicate flexible circuits during mating and unmating. Its horizontal orientation and locking mechanism provide secure connections, reducing the risk of accidental disconnections during device operation.

Rated for 250V AC voltage and 500 mA current, this connector is suitable for low power signal transmission in electronic devices and instrumentation. Operating reliably between -55°C and 85°C, it is well suited for a variety of industrial, laboratory, and commercial electronics applications.

The durable housing made from liquid crystal polymer material offers excellent dimensional stability and resistance to chemicals, ensuring connector integrity in harsh operational conditions. This product is ideal for use in telecommunications, consumer electronics, and automotive electronic systems where board-space optimization is critical.

Features 10 contacts made of phosphor bronze for excellent conductivity. Connector uses a 0.5 mm pitch suitable for compact electronic designs. Surface mount mounting type ensures easy PCB integration. Connector orientation is horizontal with locking mechanism for secure mating.

Designed to operate within -55°C to 85°C temperature range. Contact plating with tin over nickel enhances corrosion resistance. Offers zero insertion force (ZIF) to protect delicate FPC cables. Supports a maximum voltage of 250V AC and current rating of 500 mA.

Housing constructed from liquid crystal polymer ensures durability. Single row connector with dual contact position increases reliability. Explore more FPC Connectors from Wurth Elektronik on EnvMart for your precise electronic connectivity solutions.
