Molex 14-Way IDC Connector Female for Surface Mount, 1 Row, 1.27mm Pitch, 1.2A, 250V AC, Picoflex Series 90816-0014
Specifications
| Country of Origin | Ireland |
|---|---|
| Voltage | 250V ac |
| Brand | Molex |
| Orientation | Straight |
| Current | 1.2A |
| Mount Type | Surface |
| Housing Material | Polyphthalamide |
| Contact Material | Brass |
| Series | Picoflex |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.27mm |
| Contact Plating | Tin |
| Number of Contacts | 14 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shrouded/Unshrouded | Unshrouded |
Key Features
- The connector features 14 contacts arranged in a single row for high-density wire-to-board interfaces.
- It supports a current rating of 1.2A and voltage up to 250V AC.
- Designed with a 1.27mm pitch for compact PCB mounting and easy solder termination.
- Constructed from brass contacts with tin plating and housed in durable polyphthalamide material.
- Operating temperature range spans from -40°C to 105°C, making it suitable for a variety of environments.
- Unshrouded as a female IDC connector with positive latch and polarization features for enhanced retention and alignment.
- Surface mount type with straight orientation simplifies PCB assembly and reduces installation complexity.
- Ideal for automotive and consumer electronics industries requiring high vibration resistance and shock tolerance.
Product Description
Molex 90816-0014 is a 14-way IDC Connector Female designed for surface mounting on PCBs with a 1-row configuration and 1.27mm pitch. Part of the Picoflex series, it offers reliable wire-to-board interconnect solutions for demanding industrial and automotive applications.
The connector operates at currents up to 1.2A with voltage ratings of 250V AC. It is fabricated with brass contacts plated with tin for corrosion resistance and enhanced electrical contact. The housing is made of polyphthalamide, providing excellent mechanical strength and thermal stability. It supports solder termination methods, enabling secure and durable board attachment.
Operating reliably between -40°C and 105°C, this Molex connector incorporates features such as positive latches for secure retention and polarized side posts with PC pegs to ensure correct orientation during assembly. Its unshrouded female contact configuration allows for easy mating with corresponding male connectors, particularly the Mate to 90327 Series connectors.
The Picoflex PF-50 series offers approximately 50% space saving compared to traditional pitch connectors, with a low profile mated height of just 6.4mm. This makes it ideal for high-density electronic assemblies within consumer electronics and automotive control units where space and vibration resistance are critical.
The connector's robust construction delivers high resistance to vibration and shock. Polarization and integral strain relief features enhance connector reliability in harsh environments. Pre-terminated cable assemblies are available for streamlined manufacturing processes.
This product is manufactured in Ireland and supplied ready for insertion into machinery, helping improve production efficiency in industrial environments. Molex's Picoflex IDC connectors support high-density, reliable connections essential in laboratory, automotive, commercial electronics, and manufacturing applications.
For more IDC Connectors and wire housing solutions, explore the Electronics & Electricals category at EnvMart to find complementary parts and accessories from Molex and other trusted brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector has a current rating of 1.2A and supports a voltage of up to 250V AC.
The pitch of this connector is 1.27mm, designed for compact PCB mounting.
It features brass contacts with tin plating and a housing made of polyphthalamide.
The operating temperature range spans from -40°C to 105°C, making it suitable for various environments.
This connector has 14 contacts arranged in a single row.
It supports solder termination methods for secure and durable board attachment.
This model is unshrouded, allowing for easy mating with corresponding male connectors.
The connector has a straight orientation, simplifying PCB assembly and installation.
This connector is manufactured in Ireland.
It is part of the Picoflex series, which offers high-density wire-to-board interconnect solutions.
This connector is ideal for automotive and consumer electronics industries, requiring high vibration resistance and shock tolerance.
It includes positive latches for secure retention and polarized side posts for correct orientation during assembly.
