HARTING 34-Way IDC Connector Male for Through Hole, 2 Row, 320V AC, 1A, Tin Plated Contacts 09181349622

HARTING 09181349622 34-Way IDC Connector Male for Through Hole, 2 Row, rated 320V AC and 1A current, is a precision-engineered PCB transition connector designed for industrial and electronic applications requiring reliable and compact connections.

This connector features a low-profile design with a height of 5.5 mm enabling space-saving on circuit boards. It consists of two rows with a total of 34 contacts, arranged to provide efficient signal routing with a 2.54 mm pitch between pins.

The male connector features tin-plated copper alloy contacts ensuring excellent conductivity and corrosion resistance, while the polybutylene terephthalate housing provides robust mechanical strength and electrical insulation. The solder termination type with pins sized 0.635 x 0.3 mm offers a secure and stable attachment to PCBs, suitable for through-hole mounting.

Operating temperature ranges from -55°C up to 105°C, making it ideal for use in environments with wide thermal variation. It supports a maximum voltage of 320 volts AC and a current rating of 1 ampere, suitable for low-power signal and control circuits.

This connector does not include specific industry certifications but meets general quality standards for PCB connectors. Its shrouded design protects the contacts and reduces risk of accidental shorting or damage during installation and operation.

Commonly utilized in manufacturing, industrial automation, instrumentation, telecommunications, and electronic device assembly, this HARTING IDC Connector ensures dependable connectivity and operational longevity.

Designed for 34 contacts arranged in 2 rows to ensure efficient connectivity. Supports a current rating of 1 ampere with voltage up to 320V AC. Features shrouded design with male connector gender for secure mating. Mount type is through hole with straight orientation for reliable PCB mounting.

Contact plating is tin, and contact material is copper alloy for excellent conductivity. Housing made of polybutylene terephthalate offers robust insulation and durability. Operates within a temperature range from -55°C to 105°C, suitable for harsh environments.

Termination type is solder with 0.635 x 0.3 mm pins for secure electrical connections. Complies with SEK 18 series standards, ensuring compatibility and quality. Manufactured in China with new condition assurance. Explore a wide range of electronic connectors at EnvMart for your industrial and commercial needs.
