DiodesZetex 75 V 300 mA Silicon Junction General Purpose 3-Pin SOT-23 Switching Diode BAW56-7-F

DiodesZetex BAW56-7-F is a high-quality silicon junction switching diode designed for general purpose electronic applications. This diode comes housed in a compact 3-pin SOT-23 surface mount package, enabling seamless integration into automated circuit board assembly processes.

With a maximum continuous forward current rating of 300 mA and peak reverse repetitive voltage up to 75 V, the BAW56-7-F provides dependable performance in power management and signal switching tasks. It features a low maximum forward voltage of 1.25 V and minimal peak reverse current leakage of 50 μA, making it highly efficient for low power electronic circuits.

The diode exhibits a fast peak reverse recovery time of 4 nanoseconds, which supports swift switching speeds ideal for digital and analog applications in telecommunications, automotive electronics, and consumer devices.

It supports a wide operating temperature range from -65°C to 150°C, ensuring robust reliability in harsh industrial and automotive environments. The compact physical dimensions (3 mm length, 1.4 mm width, 1.1 mm height) allow designers to optimize board space without compromising electrical performance.

This diode complies with the AEC-Q101 automotive standard, certifying its suitability for rigorous automotive applications requiring quality and durability assurances.

Typical use cases include signal switching, general purpose rectification, and electronic protection circuits within industrial, automotive, telecommunications, and consumer electronics sectors.

Compact SOT-23 surface mount package suitable for automated PCB assembly. Maximum continuous forward current rating of 300 mA ensures effective switching performance. Peak reverse repetitive voltage of 75 V suitable for various electronic circuits.

Fast peak reverse recovery time of 4 ns for high-speed switching applications. Operates reliably between -65°C to 150°C temperature range for industrial use. Common anode diode configuration with general purpose rectifier characteristics.

Low peak reverse current leakage specified at 50 μA enhances circuit efficiency. Small dimensions: length 3 mm, width 1.4 mm, height 1.1 mm allow compact circuit designs. Designed to meet automotive standard AEC-Q101 ensuring high-quality and durability.
