onsemi 23 V 1 A Schottky Barrier Diode Surface Mount SOD-323 Package NSVR0320MW2T1G

onsemi NSVR0320MW2T1G is a Schottky Barrier Diode designed for surface mount applications requiring efficient low voltage, high frequency rectification and polarity protection. Its 2-pin SOD-323 package provides a compact footprint, with dimensions of 1.8 mm length, 1.35 mm width, and 0.9 mm height, making it suitable for space-constrained electronic circuits.

This diode features a maximum continuous forward current of 1 A and a peak reverse repetitive voltage of 23 V. Its maximum forward voltage drop is 500 mV, enabling low power losses in switching power supplies and freewheeling diode applications.

The device supports a minimum operating temperature of -55°C and can operate up to 125°C maximum, ensuring suitability across broad industrial, automotive, and consumer electronics environments. It complies with RoHS directives and is Pb-Free, supporting environmentally conscious designs.

The diode is automotive standard AEC-Q qualified, assuring high reliability and quality for automotive electronic systems. The small lightweight epoxy moulded SOD-323 package weighs approximately 11.7 mg and is designed for optimal automated board assembly, improving manufacturing efficiency.

This component finds extensive use in industrial control systems, automotive electronics, power management circuits, and general semiconductor applications requiring a compact, efficient rectifier with low forward voltage and fast switching characteristics.

This diode employs a Schottky barrier to achieve low forward voltage drop and fast switching. Ideal for high-frequency rectification and polarity protection in surface mount applications. Compact SOD-323 package measures 1.8 mm length, 1.35 mm width, and 0.9 mm height.

Peak reverse current is 1 mA, with a maximum forward voltage of 500 mV. Operates reliably between -55°C and 125°C, compliant with RoHS and Pb-Free standards. Automotive grade AEC-Q qualified device suitable for robust applications.

The package is epoxy moulded and designed for automated board assembly. Explore more Schottky Barrier Diodes and semiconductor components at EnvMart for your industrial, automotive, and electronic manufacturing needs.
