NXP Varactor Diode Single Element 6 V 6.4 pF 2-Pin SOD-523 BB145B,115

Free Delivery in India | Lowest Global Shipping Charges

NXP Varactor Diode Single Element 6 V 6.4 pF 2-Pin SOD-523 BB145B,115



Category Varactor Diodes Brand NXP Condition New

Specifications

Country of Origin	China
Brand	NXP
Height	0.65mm
Length	1.25mm
Model	BB145B,115
Mount Type	Surface
Series	BB145B
Maximum Operating Temperature	150°C
Package Type	SOD-523
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Diode Configuration	Single
Forward Current If	20mA
Minimum Capacitance	6.4pF
Maximum Reverse Voltage Vr	6V
Minimum Tuning Ratio	2
Tuning Ratio Test Condition	1/4 V
NXP BB145B,115 1 Single Varactor 2	1 Tuning Ratio, 6.4 pF 6 V 2-Pin SOD-523

Key Features

Single varactor diode designed for voltage-controlled capacitance applications.
Surface mount package type SOD-523 suitable for compact circuit layouts.
Operating temperature range from -55°C to 150°C ensures reliability under extreme conditions.
Forward current rating of 20 mA supports moderate current applications.
Ideal for RF tuning, frequency synthesizers, voltage-controlled oscillators, and filter circuits.
Compliant with no specific automotive standards, intended for general electronic applications.

Product Description

NXP BB145B,115 varactor diode is a surface-mount, single element varactor diode designed to provide voltage-dependent variable capacitance. It offers a maximum reverse voltage of 6 V and a minimum capacitance of 6.4 pF, packaged in a compact 2-pin SOD-523 form factor with a tuning ratio of 2:1.

This component is engineered to operate reliably across a wide temperature range, from -55°C to 150°C, making it suitable for diverse industrial and commercial electronic applications. The forward current rating of 20 mA enables it to be used in low- to moderate-power circuits.

The BB145B,115 plays a crucial role in RF tuning circuits, voltage-controlled oscillators, frequency synthesizers, and filters, where precise capacitance control based on applied voltage is necessary. Its compact physical dimensions, with a length of 1.25 mm and height of 0.65 mm, facilitate integration into densely packed printed circuit boards.

Package contents include a single varactor diode unit ready for surface mount assembly. This product is sourced from China and is in new condition. Single varactor diode designed for voltage-controlled capacitance applications.

Offers a minimum tuning ratio of 2:1 dependent on voltage. Surface mount package type SOD-523 suitable for compact circuit layouts. Operating temperature range from -55°C to 150°C ensures reliability under extreme conditions.

Forward current rating of 20 mA supports moderate current applications. Compact dimensions: length 1.25 mm and height 0.65 mm enable dense assembly. Ideal for RF tuning, frequency synthesizers, voltage-controlled oscillators, and filter circuits.

Compliant with no specific automotive standards, intended for general electronic applications. Explore more from the NXP product range and related Varactor Diodes to enhance your electronic circuit designs and manufacturing efficiency.
