NXP Single Varactor Diode 8.9:1 Tuning Ratio, 17.5 pF, 30 V, 2-Pin SOD-323 BB135,115

Free Delivery in India | Lowest Global Shipping Charges

NXP Single Varactor Diode 8.9:1 Tuning Ratio, 17.5 pF, 30 V, 2-Pin SOD-323 BB135,115



Category Varactor Diodes Brand NXP Condition New

Specifications

Country of Origin	China
Brand	NXP
Height	1.05mm
Length	1.8mm
Model	BB135,115
Mount Type	Surface
Series	BB135
Maximum Operating Temperature	125°C
Package Type	SOD-323
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Diode Configuration	Single
Forward Current If	20mA
Minimum Capacitance	17.5pF
Maximum Reverse Voltage Vr	30V
Minimum Tuning Ratio	8.9
Tuning Ratio Test Condition	0.5/28 V
NXP 1 Single Varactor 8.9	1 Tuning Ratio, 17.5 pF 30 V 2-Pin SOD-323

Key Features

This varactor diode features a single diode configuration optimized for voltage-controlled capacitance applications.
It supports a maximum reverse voltage of 30 V, suitable for moderate voltage RF circuits.
The package type is SOD-323, designed for surface mounting with compact dimensions of 1.8 mm length and 1.05 mm height.
The diode operates reliably over a temperature range from -55°C to 125°C, suitable for various industrial environments.
The diode supports a forward current of 20 mA, facilitating stable operation in voltage-controlled oscillators and frequency tuning circuits.
Designed for use in RF tuning, voltage-controlled oscillators, filters, frequency synthesizers, and multipliers.
The diode exhibits a tuning ratio test condition at 0.5/28 V, confirming capacitance variation under controlled voltage conditions.

Product Description

The NXP BB135,115 single varactor diode is engineered for electronic tuning applications requiring variable capacitance controlled by voltage. This diode offers an 8.9:1 tuning ratio and a minimum capacitance rating of 17.5 pF, making it ideal for use in RF tuning, voltage controlled oscillators, filters, frequency synthesizers, and multipliers. It is housed in a compact 2-pin SOD-323 surface-mount package, measuring 1.8 mm in length and 1.05 mm in height, allowing for efficient PCB layouts in dense electronic assemblies.

This device features a maximum reverse voltage of 30 V and can handle a forward current of up to 20 mA, ensuring robust performance in demanding operating conditions. It is designed to operate reliably across a wide temperature range from -55°C to 125°C, enabling use in various industrial and electronic environments. The diode complies with general semiconductor standards but is not rated for automotive applications.

As a varicap or tuning diode, the BB135,115 varies capacitance in response to the applied voltage, with a tuning ratio test performed at 0.5/28 V to verify its performance. This predictable capacitance variation allows it to be used effectively in precision RF circuits and adjustable filter designs.

This varactor diode is suitable for industrial, laboratory, and manufacturing environments requiring precise capacitance control. Its surface-mount package supports automated assembly processes, improving production efficiency for OEMs.

NXP's wide range of semiconductor components provides solutions for switching diode and varactor diode applications. The reliable manufacturing origin in China ensures consistent quality and supply. Ideal for electronic engineers and designers implementing voltage-controlled capacitance devices.
