DiodesZetex 30 V 2 A Single Barrier Diode 2-Pin Surface Mount PowerDI123 SBR2U30P1-7

DiodesZetex SBR2U30P1-7 Schottky Barrier Diode is a 30 V, 2 A rated single diode designed for surface mount applications using the PowerDI123 package. It is engineered to provide low forward voltage drop and high thermal stability, making it highly reliable for power rectification needs in industrial, automotive, and electronics manufacturing sectors.

This diode operates efficiently within a temperature range of -65°C to 150°C and supports a peak non-repetitive forward surge current of 75 A, ensuring robustness against transient currents. Its compact package, measuring 3 mm in length, 1.93 mm in width, and 1 mm in height, supports efficient PCB layout and integration.

The SBR2U30P1-7 belongs to the Super Barrier Rectifier series, which combines low forward voltage characteristics with the ruggedness of PN epitaxial diodes. The diode configuration is single, with a barrier-type rectifier, designed to improve power efficiency and minimize energy losses.

This product complies with the automotive qualification standard AEC-Q101, ensuring enhanced quality and reliability under stringent automotive conditions. The diode is ideal for use in power supplies, automotive electronics, and various semiconductor applications requiring efficient switching and rectification.

The diode is manufactured in China following stringent quality standards and is supplied as new product condition. It is typically employed in industrial and automotive electronic assemblies for enhanced performance and durability.

Surface mount diode designed for power rectification applications. Maximum continuous forward current of 2 amperes. Peak reverse repetitive voltage rated at 30 volts. Low forward voltage drop of 400 millivolts for improved efficiency.

Operating temperature range from -65°C to 150°C. Compact dimensions with 3 mm length, 1.93 mm width, and 1 mm height. Offers high surge current capability up to 75 amperes. Compliant with AEC-Q101 automotive standards for reliability.

Constructed as a single diode in a barrier rectifier configuration with 2 pins. Manufactured in China, suitable for industrial and automotive electronic designs. Explore more Schottky Barrier Diodes and other semiconductor components at EnvMart for your industrial, automotive, and electronics manufacturing needs.
