Nexperia Switching Diode Single Silicon Junction 250 mA 125 V MiniMELF BAS45AL,115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.6mm |
| Length | 3.7mm |
| Model | BAS45AL,115 |
| Width | 1.6mm |
| Mount Type | Surface |
| Series | BAS45AL |
| Maximum Operating Temperature | 175°C |
| Package Type | MiniMELF |
| Sub Type | Silicon Junction |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Power Dissipation Pd | 300mW |
| Diode Configuration | Single |
| Maximum Forward Voltage Vf | 1V |
| Peak Reverse Recovery Time trr | 4ns |
| Maximum Forward Current If | 250mA |
| Maximum Peak Reverse Repetitive Voltage Vrrm | 125V |
| onsemi Silicon Junction, Single, 200 mA, 2-Pin DO-35 FDLL300ABrand | onsemi |
Key Features
- Maximum forward current is 250 mA for small signal applications.
- Low forward voltage drop of 1 V for efficient switching.
- Fast peak reverse recovery time of 4 ns ideal for high-speed switching.
- Surface mount MiniMELF package ensures easy PCB integration.
- Operates reliably between -65°C and 175°C temperature range.
- Single diode configuration with 2 pins for circuit designs.
- Maximum power dissipation rated at 300 mW for durability.
- Silicon junction diode suitable for switching and signal applications.
Product Description
Nexperia BAS45AL,115 is a single silicon junction switching diode designed for switching and signal applications. It supports a maximum forward current of 250 mA and peak reverse voltage of 125 V, housed in a compact MiniMELF surface mount package measuring 3.7 mm by 1.6 mm by 1.6 mm.
This diode features a low forward voltage of 1 V and an exceptionally fast peak reverse recovery time of 4 nanoseconds, making it ideal for high-frequency switching circuits in industrial, automotive, and consumer electronics.
Operable within a wide temperature range from -65°C to 175°C, it ensures reliable function under varied environmental conditions. The maximum power dissipation of 300 mW supports stability during continuous operation in demanding applications.
The small signal switching diode supports customized high density circuit designs, offering low leakage and high voltage capabilities with minimal capacitance. The MiniMELF package enables automated pick-and-place assembly processes, improving production efficiency.
Maximum forward current is 250 mA for small signal applications. Low forward voltage drop of 1 V for efficient switching. Fast peak reverse recovery time of 4 ns ideal for high-speed switching. Surface mount MiniMELF package ensures easy PCB integration.
Operates reliably between -65°C and 175°C temperature range. Compact dimensions support versatile PCB mounting options. Maximum power dissipation rated at 300 mW for durability. Silicon junction diode suitable for switching and signal applications.
Not certified for automotive standards.
This switching diode is widely applicable in electronic circuit designs involving industrial controls, power management, signal switching, and more. Its reliable performance and compact design make it suitable for electronics manufacturing, prototyping, and repairs.
Explore more high quality semiconductor products from Nexperia in the Switching Diode category at EnvMart for your electronics component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum forward current for the BAS45AL,115 is 250 mA, making it suitable for small signal applications.
This diode has a peak reverse voltage rating of 125 V, which is essential for its operation in various electronic circuits.
The BAS45AL,115 features a low forward voltage drop of 1 V, which contributes to efficient switching performance.
It has a fast peak reverse recovery time of 4 nanoseconds, making it ideal for high-speed switching applications.
The BAS45AL,115 operates reliably within a temperature range of -65°C to 175°C, ensuring functionality under varied environmental conditions.
The MiniMELF package of this diode measures 3.7 mm in length, 1.6 mm in width, and 1.6 mm in height, allowing for compact PCB integration.
The maximum power dissipation for the BAS45AL,115 is rated at 300 mW, supporting stability during continuous operation.
This model features a single diode configuration with 2 pins, suitable for various circuit designs.
The BAS45AL,115 supports surface mounting, facilitating easy integration onto printed circuit boards (PCBs).
It is suitable for switching and signal applications, commonly found in industrial controls, power management, and consumer electronics.
This product has a single diode configuration, making it versatile for various electronic circuit designs.
The BAS45AL,115 is not certified for automotive standards, so it should be used in applications outside of automotive environments.
