Vishay Single-Phase Bridge Rectifier 200 V 300 A 4-Pin Through Hole GBPC2502W-E4/51

Free Delivery in India | Lowest Global Shipping Charges

Vishay Single-Phase Bridge Rectifier 200 V 300 A 4-Pin Through Hole GBPC2502W-E4/51

Name: Vishay Single-Phase Bridge Rectifier 200 V 300 A 4-Pin Through Hole GBPC2502W-E4/51
Brand: Vishay
SKU: 375547
Price: 4.54 USD
Availability: InStock



Category Bridge Rectifiers Brand Vishay Condition New

Specifications

Country of Origin	China
Brand	Vishay
Height	7.87mm
Length	28.8mm
Model	GBPC2502W-E4/51
Width	28.8mm
Mount Type	Through Hole
Series	GBPC25
Configuration	Single
Maximum Operating Temperature	150°C
Package Type	GBPC
Minimum Operating Temperature	-55°C
Number of Phases	1
Pin Count	4
Peak Reverse Repetitive Voltage Vrrm	200V
Peak Reverse Current Ir	500μA
Peak Non-Repetitive Forward Surge Current Ifsm	300A
Forward Current If	25A
Peak Forward Voltage Vf	1.1V

Key Features

Offers high surge current capability and low typical reverse current.
Glass passivated semiconductor for enhanced reliability.
Maximum operating temperature of 150°C allows robust performance.
Designed for PCB through hole mounting with a GBPC package.
Forward voltage drop of 1.1 V ensuring efficiency in power conversion.
Operating temperature range from -55°C to 150°C for versatile applications.
Single-phase configuration with 4 pins ensures standard compatibility.

Product Description

Vishay GBPC2502W-E4/51 Bridge Rectifier is a single-phase, 4-pin device designed for converting alternating current (AC) to direct current (DC) in full-wave rectification applications. Rated for a peak repetitive voltage of 200 V and a high surge current capability of 300 A, it is suitable for demanding industrial and electronic power circuits.

The device features glass passivated semiconductor technology which ensures a low typical reverse current (500 μA) and high reliability in operation. The rectifier supports a continuous forward current of 25 A and operates safely at temperatures ranging from -55°C to 150°C, making it ideal for use in harsh environmental conditions.

Its compact GBPC package measures 28.8 mm in length and width and 7.87 mm in height, with a through-hole mount type for easy integration on printed circuit boards (PCBs). With a forward voltage of 1.1 V, the device optimizes power efficiency.

This bridge rectifier finds application in industrial machines, power supplies, electronic assemblies, and HVAC systems requiring robust and efficient AC-to-DC conversion. Its high dielectric strength of 1500 Vrms enhances safety and durability.

High surge current capability of 300 A for transient loads. Glass passivated structure for improved longevity and performance. Compact and durable GBPC package for through-hole mounting. Wide operating temperature range for varied industrial environments.

Low forward voltage drop of 1.1 V enhances efficiency. Peak reverse repetitive voltage rating of 200 V. Designed for single-phase AC-to-DC conversion. Ideal for semiconductor, industrial, and power connector applications.

This Vishay bridge rectifier is made in China and sold in new condition. It is categorized under discrete semiconductors and bridge rectifiers, making it essential for modern electronic and electrical power applications.
