Vishay Bridge Rectifier, Surface Mount, 600 V Peak Reverse Voltage, 50 A Surge Current, 4-Pin Single DF06S-E3/77

Free Delivery in India | Lowest Global Shipping Charges

Vishay Bridge Rectifier, Surface Mount, 600 V Peak Reverse Voltage, 50 A Surge Current, 4-Pin Single DF06S-E3/77

Name: Vishay Bridge Rectifier, Surface Mount, 600 V Peak Reverse Voltage, 50 A Surge Current, 4-Pin Single DF06S-E3/77
Brand: Vishay
SKU: 356000
Price: 0.49 USD
Availability: InStock



Category Bridge Rectifiers Brand Vishay Condition New

Specifications

Country of Origin	China
Brand	Vishay
Height	3.3mm
Length	8.51mm
Model	DF06S-E3/77
Width	6.5mm
Mount Type	Surface
Series	DF
Configuration	Single
Maximum Operating Temperature	150°C
Package Type	DFS
Minimum Operating Temperature	-55°C
Number of Phases	1
Pay online using	Or choose to pay later via bank transfer
RS Stock No.	710-2881PBrand: VishayManufacturers Part No.: DF06S-E3/77
Pin Count	4
Peak Reverse Repetitive Voltage Vrrm	600V
Peak Reverse Current Ir	5μA
Peak Non-Repetitive Forward Surge Current Ifsm	50A
Forward Current If	1A
Peak Forward Voltage Vf	1.1V

Key Features

Capable of operating at a maximum temperature of 150°C.
Operates with a forward current of 1 A and peak forward voltage of 1.1 V.
Designed for surface mount with DFS package type.
Supports a minimum operating temperature of -55°C for wide environmental tolerance.
Exhibits low peak reverse current of 5 µA for improved efficiency.
Ideal for automated PCB placement and reflow soldering processes.
Provides high reliability and thermal performance with the DF series design.

Product Description

Vishay DF06S-E3/77 bridge rectifier is a high-performance semiconductor component engineered for power rectification applications in electronic devices and circuits. Featuring a peak reverse repetitive voltage rating of 600 V and a peak non-repetitive forward surge current of 50 A, this device is well-suited for ensuring reliable AC to DC conversion in demanding industrial, commercial, and electronics manufacturing environments.

The bridge rectifier employs a single phase, 4-pin configuration housed in a compact DFS surface mount package optimized for automated PCB assembly and reflow soldering techniques. Its electrical characteristics include a forward current rating of 1 A, a low peak forward voltage drop of 1.1 V, and minimal reverse leakage current of 5 µA, which collectively enhance circuit efficiency and thermal management.

Designed for operation within a wide temperature range from -55°C up to 150°C, this component provides robust performance and longevity under challenging environmental conditions. The small size with dimensions of 8.51 mm length, 6.5 mm width, and 3.3 mm height makes it ideal for space-constrained circuit board layouts.

Vishay’s DF series Bridge Rectifiers are recognized for their high surge current capability and reliable operation, making this model suitable for various industrial, laboratory, HVAC, manufacturing, and power supply applications where stable and efficient rectification is critical.

High surge current capability supports transient loads. Low DC reverse current optimizes power efficiency. Surface mount DFS package reduces mounting footprint. Compatible with automated PCB reflow soldering processes. Compact form factor ensures flexible circuit design.

Operating temperature range supports diverse industrial environments. Single phase bridge rectifier topology for full wave rectification. Reliable thermal performance ensures device longevity.

This Vishay bridge rectifier DF06S-E3/77 is a trusted choice for engineers and designers looking for durable, reliable, and efficient power rectification solutions. Explore our catalog for more semiconductor and discrete component options optimized for your industry needs.
