DiodesZetex 4-Element Uni-Directional TVS Diode Array, 6-Pin SOT-363 D1213A-04S-7
Specifications
| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1mm |
| Length | 2.2mm |
| Model | D1213A-04S-7 |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | D1213A |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-363 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 6 |
| Number of Elements per Chip | 4 |
| Clamping Voltage VC | 17V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Complex Array |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 6V |
| Maximum Reverse Stand-off Voltage Vwm | 3.3V |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 5A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Provides 4-element uni-directional protection in a compact SOT-363 package.
- Minimum breakdown voltage of 6 V ensures effective transient suppression.
- Maximum peak pulse current of 5 A supports robust surge protection.
- Operating temperature range from -55°C to 150°C for reliable performance.
- Clamping voltage of 17 V protects circuits from voltage spikes.
- Low maximum reverse leakage current of 1 μA to minimize power loss.
- Pin count of 6 facilitates multiple line protection in applications.
- Complies with automotive standard AEC-Q101 for quality assurance.
Product Description
DiodesZetex D1213A-04S-7 is a 4-element uni-directional transient voltage suppression (TVS) diode array packaged in a 6-pin SOT-363 surface mount device. Designed for protecting sensitive electronic components and data lines against voltage spikes and electrostatic discharge, this diode array offers reliable and compact surge suppression.
The device features a minimum breakdown voltage of 6 V and a maximum reverse stand-off voltage of 3.3 V, effectively safeguarding circuits from transient overvoltage conditions. It delivers a maximum peak pulse current of 5 A and low reverse leakage current of 1 μA, ensuring efficient protection with minimal power consumption.
This TVS diode array complies with the automotive industry standard AEC-Q101, confirming its suitability for demanding environments. Its temperature handling range extends from -55°C to 150°C, making it appropriate for industrial and automotive applications.
The compact SOT-363 package, measuring 2.2 mm in length, 1.35 mm in width, and 1 mm in height, allows easy integration into high-density printed circuit boards. The 6-pin configuration supports multi-line data protection in a single device, simplifying design complexity.
4-element uni-directional array in SOT-363 package for space-saving installation. Breakdown voltage of 6 V and clamping voltage of 17 V for effective surge protection. High peak pulse current capacity of 5 A for transient robustness.
Wide operating temperature range (-55°C to 150°C) ensures reliable performance. Automotive qualified to AEC-Q101 for use in automotive electronics. This diode array is commonly used in industrial controls, communication devices, automotive electronics, and consumer devices requiring multi-line ESD and transient protection.
EnvMart offers this DiodesZetex TVS diode array as a dependable component for electronics manufacturers seeking durable transient voltage suppression solutions. Explore similar TVS Diode Arrays and discrete semiconductors in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The minimum breakdown voltage is 6 V, which ensures effective transient suppression.
It supports a maximum peak pulse current of 5 A, providing robust surge protection.
The clamping voltage is 17 V, which protects circuits from voltage spikes.
The operating temperature range is from -55°C to 150°C, ensuring reliable performance in various environments.
It is packaged in a compact SOT-363 surface mount device, measuring 2.2 mm in length, 1.35 mm in width, and 1 mm in height.
This model features a pin count of 6, facilitating multiple line protection in applications.
It complies with the automotive standard AEC-Q101, ensuring quality assurance for automotive applications.
The maximum reverse leakage current is 1 μA, which helps minimize power loss.
It uses a complex array configuration, providing effective protection for sensitive components.
The maximum reverse stand-off voltage is 3.3 V, effectively safeguarding circuits from transient overvoltage conditions.
This diode array is commonly used in industrial controls, communication devices, automotive electronics, and consumer devices requiring multi-line ESD and transient protection.
The height of the SOT-363 package is 1 mm, allowing for easy integration into high-density printed circuit boards.
