HARTING 60-Way IDC Connector Male for Cable, 2 Row 09181609622

Free Delivery in India | Lowest Global Shipping Charges

HARTING 60-Way IDC Connector Male for Cable, 2 Row 09181609622

Name: HARTING 60-Way IDC Connector Male for Cable, 2 Row 09181609622
Brand: HARTING
SKU: 213118
Price: 4.42 USD
Availability: InStock



Category IDC Connector Brand HARTING Condition New

Specifications

Country of Origin	China
Voltage	320V ac
Brand	HARTING
Orientation	Right Angle
Current	1A
Mount Type	Cable
Housing Material	Polybutylene Terephthalate
Contact Material	Copper Alloy
Series	SEK 18
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Tin
Number of Contacts	60
Contact Gender	Male
Connector Gender	Male
Shrouded/Unshrouded	Shrouded

Key Features

Features 60 contacts arranged in 2 rows for compact design.
Operates at a current rating of 1A and voltage of 320V AC.
Pitch between contacts is 2.54 mm ensuring precision connections.
Right angle orientation facilitates space-saving in installations.
Contact plating is tin over copper alloy for reliable conductivity.
Housing made of durable polybutylene terephthalate material.
Termination is IDC (Insulation Displacement Contact) type for quick cable assembly.
Designed for operating temperatures from -55°C up to 105°C.

Product Description

HARTING 09181609622 is a 60-Way IDC Connector Male designed for cable mounting with a two-row contact layout. It is an ideal choice for electronic components and power connections, providing robust and reliable interfacing in complex wiring harnesses and PCB transition applications.

This connector supports a current of 1A and a voltage rating of 320V AC, suitable for various electronic and industrial control systems. The 2.54 mm pitch ensures precise contact spacing and signal integrity.

The connector features a shrouded male interface with tin-plated copper alloy contacts for enhanced conductivity and corrosion resistance. Its housing is made from polybutylene terephthalate, offering excellent insulation and mechanical stability.

Termination is by IDC type, allowing for efficient and secure cable assembly without soldering, compatible with flat cables of 1.27 mm pitch and AWG 28/7 conductors. Its maximum operating temperature of 105°C and minimum of -55°C make it suitable for harsh environmental conditions.

Features 60 contacts arranged in 2 rows for compact design. Operates at a current rating of 1A and voltage of 320V AC. Pitch between contacts is 2.54 mm ensuring precision connections. Right angle orientation facilitates space-saving in installations.

Contact plating is tin over copper alloy for reliable conductivity. Housing made of durable polybutylene terephthalate material. Termination is IDC (Insulation Displacement Contact) type for quick cable assembly. Designed for operating temperatures from -55°C up to 105°C.

Series SEK 18 connector known for PCB transition applications. Manufactured in China with high standard quality materials.

This HARTING IDC Connector is widely used in electronic equipment, industrial automation, manufacturing, and power distribution systems. It enhances production efficiency by providing a reliable and easy-to-install cable connection solution.
