HARTING 50-Way IDC Connector Male for Cable, 2 Row, 320V AC, 1A, SEK 18 Series 09181509622

HARTING 09181509622 50-Way IDC Connector Male for Cable, 2 Row is a precision-engineered PCB transition connector designed for secure and efficient wiring in electronic assemblies. Rated for 320V AC voltage and supports a current of 1A, it is ideal for industrial, manufacturing, and electronic applications requiring reliable signal and power transmission.

This connector features 50 copper alloy contacts plated with tin to ensure low resistance and durability. The contacts are housed in a polybutylene terephthalate body, offering robust mechanical strength and chemical resistance, ensuring durability in demanding environments.

The 2-row configuration with a 2.54mm pitch and right-angle cable mount optimizes space on PCBs and facilitates easy cable management. It accommodates IDC flat cables with 1.27mm pitch, making it suitable for high-density wiring solutions. Operating temperature range from -55°C to 105°C enables usage in both cold and hot industrial environments.

The connector belongs to the SEK 18 series and utilizes tin-plated solder pins measuring 0.635 x 0.3 mm, providing reliable electrical connections. Its shrouded male design protects contacts and enhances connection reliability.

Features 50 contacts arranged in 2 rows for efficient cable connections. Designed with a shrouded male connector to ensure secure and safe mating. Constructed with copper alloy contacts plated in tin for corrosion resistance.

Housing made of durable polybutylene terephthalate suitable for industrial applications. Operates reliably within a temperature range of -55°C to 105°C. Pitch between contacts is 2.54mm with solder pins sized 0.635 x 0.3 mm.

Right angle orientation cable mount for space-saving installations. Termination type is IDC, compatible with flat cables of 1.27 mm pitch AWG 28/7.

This connector is widely used in electronics manufacturing, automation systems, industrial controls, and communication equipment, providing a dependable interface between PCB and cable assemblies. Its robust construction and compliance with industrial operating conditions make it an essential component for professionals requiring durable and precise IDC Connectors.
