Amphenol Industrial SURLOK PLUS RADSOK EV Connector Female 200A 1000V Panel Mount IP67 SLPRBTNNR / C10-731842-200
Specifications
| Country of Origin | China |
|---|---|
| Brand | Amphenol Industrial |
| Colour | Red |
| Orientation | Straight |
| Current | 200A |
| Height | 19mm |
| Model | SLPRBTNNR / C10-731842-200 |
| Depth | 46.2mm |
| IP Rating | IP67 |
| Connector Type | RADSOK |
| Width | 19mm |
| Mount Type | Panel Mount |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | SURLOK PLUS |
| Termination Type | Screw |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Pin Diameter | 8mm |
| Number of Rows | 1 |
| Wire size | 35, 50mm² |
| Operating Voltage | 1000V |
| For Use With | SurLok 1-Position Plug |
| Standards/Approvals | UL 94-V0 |
| Number of Contacts | 1 |
| Contact Gender | Male |
| Connector Gender | Female |
| Better World Claim | Renewable Energy Solution |
Key Features
- Supports a maximum current of 200A at 1000V operating voltage.
- Equipped with R4 RADSOK technology for high tensile strength and conductive connection.
- Features a female connector with a single male contact and straight orientation.
- Constructed with a copper alloy contact and thermoplastic housing for durability.
- Rated IP67 for protection against dust and water ingress.
- Suitable for panel mount applications with a compact 19mm height and width, and 46.2mm depth.
- Operates reliably between temperatures of -40°C to 125°C.
- Compliance with UL 94-V0 flammability standards ensures safety in harsh environments.
Product Description
Amphenol Industrial SLPRBTNNR / C10-731842-200 is a high-performance SURLOK PLUS RADSOK EV Connector Female rated for 200A current and designed for demanding industrial and automotive electrical applications. Operating at 1000V, this connector integrates R4 RADSOK technology to deliver superior connection integrity with high tensile strength and a highly conductive surface area. The 8mm pin diameter female connector features a straight orientation and spring locking mechanism to ensure a secure, touch-proof, and keyed connection that prevents mismating.
Constructed with a copper alloy contact and a robust thermoplastic housing, this SurLok Plus receptacle offers excellent durability and environmental resistance. With an IP67 protection rating, it is fully sealed against dust and water, making it suitable for harsh environments. The connector is panel mounted and compact, measuring 19mm in height and width, and 46.2mm in depth, facilitating easy installation and space efficiency.
The product has a wide operating temperature range from -40°C to 125°C and meets UL 94-V0 flammability standards for safety and compliance. It is commonly utilized in Electric Vehicle (EV) and Hybrid Electric Vehicle (HEV) applications, battery management systems, rail mass transit, process control, and medical equipment sectors.
Supports 200A current at 1000V operating voltage. Utilizes R4 RADSOK technology for high conductivity and tensile strength. Features a female connector with a single male contact and spring locking. Copper alloy contacts and thermoplastic housing enhance durability.
IP67 rated for dust and water ingress protection. Compact panel mount design with dimensions 19mm x 19mm x 46.2mm. Temperature range from -40°C to 125°C suitable for various environments. Meets UL 94-V0 flammability standards ensuring safety.
Ideal for EV/HEV, rail transit, battery management, process control, and medical use. Red color and keyed design prevent installation errors.
This Amphenol SURLOK PLUS connector exemplifies reliability and ease of installation for high current EV and industrial electrical connector needs. Explore the comprehensive range of EV Connectors from Amphenol Industrial on EnvMart for enhanced power connectivity solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a maximum current of 200A.
The operating voltage is rated at 1000V.
This model features a RADSOK connector type with a female connector and a single male contact.
It is rated IP67, providing protection against dust and water ingress.
The connector has a compact design with dimensions of 19mm in height, 19mm in width, and 46.2mm in depth.
It is constructed with a copper alloy contact and a thermoplastic housing for durability.
It operates reliably between -40°C to 125°C.
It is commonly utilized in Electric Vehicle (EV) and Hybrid Electric Vehicle (HEV) applications, battery management systems, rail mass transit, process control, and medical equipment sectors.
The pin diameter is 8mm.
It complies with UL 94-V0 flammability standards, ensuring safety in harsh environments.
This model is designed for panel mount applications.
It is compatible with wire sizes of 35mm² and 50mm².
