Molex KK 396 Series Straight Through Hole Pin Header, 11 Contacts, 3.96 mm Pitch, 1 Row, Unshrouded 26-60-4110

Molex 26-60-4110 KK 396 Series Straight Through Hole Pin Header is a high-quality, reliable electronic component designed for wire-to-board connections. It features 11 male contacts arranged in a single row with a precise 3.96 mm pitch spacing. The connector's polyester housing provides robust insulation and mechanical strength, ensuring consistent performance even under demanding environmental conditions.

Each brass contact is tin-plated to improve corrosion resistance and electrical conductivity, making this pin header suitable for industrial, commercial, and manufacturing electronic assemblies. Rated for 7A current and 250V voltage, it supports a wide range of power and signal transmission needs.

The through-hole mounting type ensures strong mechanical retention on printed circuit boards, while the solder termination allows secure and stable joints. Operating temperature tolerance from -40°C to 80°C enables reliable use in various industrial environments, including testing and laboratory equipment, industrial controls, and automation systems.

This connector series mates seamlessly with other Molex housings like the 2139, 3069, 6442, 41695 series, and board connectors 2145 and 41815, offering versatile integration options for custom electronic solutions.

The pin header features a straight orientation with a 3.96 mm pitch between contacts. Constructed with a polyester housing for durability and heat resistance. Contact material is brass plated with tin to ensure reliable connectivity.

Supports a current rating of 7 amperes and a maximum operating voltage of 250 volts. Operates in temperatures ranging from -40°C to 80°C, providing suitability across various industrial environments. The connector system is wire-to-board with a through-hole mount type for sturdy PCB integration.

Termination type is solder, ensuring secure electrical connections. Ideal for applications in electronics manufacturing, industrial control systems, and PCB assembly.

This product is an essential component for electronic engineers and manufacturers involved in the design and production of reliable printed circuit boards. Explore more Molex connectors and associated components within the Electronics & Electricals category on EnvMart, ensuring top-quality solutions for professional installations.
