Molex C-Grid III Series Straight Through Hole Pin Header 26 Contacts 2.54 mm Pitch 2 Row Unshrouded 90131-0133

Free Delivery in India | Lowest Global Shipping Charges

Molex C-Grid III Series Straight Through Hole Pin Header 26 Contacts 2.54 mm Pitch 2 Row Unshrouded 90131-0133

Name: Molex C-Grid III Series Straight Through Hole Pin Header 26 Contacts 2.54 mm Pitch 2 Row Unshrouded 90131-0133
Brand: Molex
SKU: 206730
Price: 2.17 USD
Availability: InStock



Category PCB Pin Header Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	350V
Brand	Molex
Orientation	Straight
Current	3A
Mount Type	Through Hole
Housing Material	Polyester
Contact Material	Brass
Series	C-Grid III
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Tin
Number of Contacts	26
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board
Tail Pin Length	2.9mm
Mating Pin Length	6.75mm

Key Features

Designed for wire-to-board applications with through hole mount type.
Constructed with brass contacts plated with tin for reliable connectivity.
Features a breakaway design for customizable length configuration.
Operates within temperature range of -55°C to 125°C with rated voltage of 350V.
High mechanical stability after soldering ensures secure connections.
Suitable for industrial, computer, medical, consumer electronics, and automotive systems.
Straight orientation with male contact gender for optimal mating with sockets and crimp housings.
Compliance with latest industry requirements for C-Grid III interconnection systems.

Product Description

Molex 90131-0133 C-Grid III Series Straight Through Hole Pin Header with 26 contacts features a 2.54 mm pitch in a dual-row configuration. This unshrouded pin header is designed for wire-to-board connections, facilitating reliable and secure mating in PCB assemblies. The contacts are made of brass with tin plating, providing excellent electrical conductivity and corrosion resistance.

The header supports a current rating of 3A and operates safely within a voltage rating of 350V. It is capable of functioning in harsh environments with an operating temperature range from -55°C to 125°C. The breakaway design allows customization of the number of contacts to fit specific design needs, enhancing design flexibility.

These pin headers exhibit a high retention force ensuring secure connections and high mechanical stability post-soldering, making them ideal for demanding industrial, computer, medical, telecommunications, consumer electronics, and automotive applications. Suitable for desktop PCs, servers, monitors, medical devices, and automotive safety systems, they are a versatile choice for various PCB interconnection requirements.

Designed for wire-to-board applications with through hole mount. Brass contact material with tin plating ensures durability and conductivity. Breakaway feature for adjustable pin count and design flexibility. High retention force provides stable and secure mating.

Operates over a wide temperature range from -55°C to 125°C. Supports current up to 3A and voltage up to 350V. Straight orientation and unshrouded for easy integration. Made from durable polyester housing material suitable for industrial use.

The 2-row design with 26 contacts is compatible with corresponding C-Grid III sockets.

Available as part of the Molex C-Grid III family, this pin header is widely used in various industrial sectors, laboratories, manufacturing, and automotive electronics. It offers exceptional performance and flexibility for modern interconnection needs. For more PCB connectors and headers, browse the comprehensive listings and select quality Molex connectors at EnvMart today.

Explore more products in our PCB Pin Header category.
