Molex C-Grid III Series Straight Through Hole Pin Header 4 Contact, 2.54 mm Pitch, 2 Row Unshrouded 90131-0122

Molex 90131-0122 C-Grid III Series Straight Through Hole Pin Header is a high-quality PCB connector component designed to provide secure and stable connections for electronic circuits. Featuring 4 contacts arranged in 2 rows with a 2.54 mm pitch and unshrouded configuration, this connector is ideal for wire-to-board applications where reliability and mechanical stability are crucial.

The pin header uses a through-hole mount type for strong soldered fixation on PCB boards. Contacts are made of brass with tin plating, ensuring excellent conductivity, corrosion resistance, and durability even in harsh industrial environments. Rated for 3 amps current and 350 volts operating voltage, it is suitable for a wide range of electrical applications across industrial, medical, computer, and automotive sectors.

Operating temperatures range from -55°C to 125°C, making it suitable for challenging environments. The connector pins feature a 2.9 mm tail pin length for soldering and a 6.75 mm mating pin length to mate securely with matching connectors. The breakaway design allows custom sizing for flexible PCB layout and design requirements.

This pin header is compatible with other C-Grid III series sockets and crimp housings, facilitating a versatile interconnection solution that supports board-to-board and wire-to-board configurations. The unshrouded two-row design supports easy access for mating and unmating without tool intervention.

Provides reliable connection with 4 male contacts and 2-row design. Through hole mounting type ensures strong physical soldering to PCB. Brass contacts plated with tin provide durability and conductivity. Supports operating voltage up to 350 V and current rating of 3 A.

Operates in temperature range from -55°C to 125°C for versatile use. Pins feature a 2.9 mm tail length and 6.75 mm mating length for secure connections. Unshrouded header design facilitates easy mating and breakaway for design flexibility.

Compatible with C-Grid III series PCB sockets and crimp housings. Wide industrial applicability including computer, medical, telecommunications, and automotive electronics.

Molex C-Grid III connectors are widely adopted in demanding industrial and commercial applications such as desktop PCs, servers, medical devices, telecommunications equipment, industrial machinery, and automotive electronic safety systems. Their design emphasizes both electrical performance and mechanical durability, supporting long-term reliable operation.

Choose this Molex 90131-0122 pin header for your PCB connection needs to ensure quality, robust, and flexible board interconnections.
