Phoenix Contact PT 2.5/8-7.5-H Series Straight PCB Terminal Block, 8 Contacts, 7.5 mm Pitch, 32A, 800V 1988163

Free Delivery in India | Lowest Global Shipping Charges

Phoenix Contact PT 2.5/8-7.5-H Series Straight PCB Terminal Block, 8 Contacts, 7.5 mm Pitch, 32A, 800V 1988163

Name: Phoenix Contact PT 2.5/8-7.5-H Series Straight PCB Terminal Block, 8 Contacts, 7.5 mm Pitch, 32A, 800V 1988163
Brand: PHOENIX CONTACT
SKU: 201649



Category PCB Terminal Block Brand PHOENIX CONTACT Condition New

Specifications

Country of Origin	Bulgaria
Voltage	800V
Brand	Phoenix Contact
Orientation	Straight
Current	32A
Model	1988163
Housing Material	Polyamide
Series	PT 2.5/8-7.5-H
Number of Rows	1
Pitch	7.5mm
Number of Contacts	8
DIN EN 60512-5-2	2003-01

Key Features

Equipped with 8 contacts ensuring reliable electrical connection.
7.5 mm pitch spacing for compact PCB integration.
Supports a current rating of 32A and voltage of 800V.
Constructed with robust polyamide housing for durability.
Single-row straight orientation simplifies PCB layout design.
Suitable for solid and flexible wires from 0.5 mm² to 4.0 mm².
Manufactured in Bulgaria ensuring high-quality standards.

Product Description

Phoenix Contact 1988163 PT 2.5/8-7.5-H Series Straight PCB Terminal Block is engineered for dependable PCB wiring in industrial, manufacturing, and electronics applications. This terminal block features an 8-contact configuration with a 7.5 mm pitch, enabling efficient space utilization on printed circuit boards.

The housing is made from polyamide material, ensuring mechanical stability and resistance to environmental factors. It supports a maximum current of 32 amperes and voltage rating up to 800 volts, making it suitable for a variety of electrical circuits.

This single-row, straight orientation terminal block facilitates straightforward wiring and maintenance. It accepts solid and flexible conductors with cross-sections ranging from 0.5 mm² to 4.0 mm² (20-10 AWG), providing versatility for different wiring needs.

Designed without integrated standards or approvals, this model is still compliant with DIN EN 60512-5-2:2003-01, reflecting adherence to recognized industrial benchmarks. The block’s rugged design supports larger cross-sections and higher voltages, incorporating plus/minus screw technology for secure connections.

Manufactured in Bulgaria, the Phoenix Contact PT Series terminal blocks offer high terminal capacity thanks to their rectangular terminal block spacing and are rated to UL94V-0 flammability standards.

Equipped with 8 contacts ensuring reliable electrical connection. 7.5 mm pitch spacing for compact PCB integration. Supports a current rating of 32A and voltage of 800V. Constructed with robust polyamide housing for durability.

Single-row straight orientation simplifies PCB layout design. Accepts solid and flexible wires from 0.5 mm² to 4.0 mm² (20-10 AWG). Complies with DIN EN 60512-5-2:2003-01 standards. Manufactured in Bulgaria ensuring product quality.

This product is ideal for applications in industrial electronics, manufacturing assembly lines, power distribution boards, and electronic instrumentation. Explore more Phoenix Contact products and related PCB Terminal Blocks available on EnvMart for comprehensive electronic component solutions.
