Wieland 8593 Series PCB Terminal Block, 4-Contact, 3.5 mm Pitch, Wave Soldering Mount, Grey, 10A, Straight 25.195.0453.0

The Wieland 25.195.0453.0 PCB Terminal Block from the 8593 Series is engineered to provide reliable and robust electrical connections for printed circuit boards. Designed with four contacts in a single row, this terminal block features a 3.5 mm pitch and straight orientation, ensuring easy integration with electronic components and industrial systems.

Constructed from high-quality materials, the terminal bodies are made of nickel-plated brass, the contact clamp is tinned bronze, and the tightening screws are nickel-plated galvanised steel for maximum durability and corrosion resistance. The clamping arrangement secures wires while protecting them from mechanical stress. The block is suitable for wave soldering mounts, facilitating efficient assembly in mass production environments.

Supporting wire sizes from 0.14 mm² to 1.5 mm² and 30 to 16 AWG, it is rated for a current of up to 10A and a voltage of 300V - making it suitable for a broad range of industrial, automation, data processing, and instrumentation applications. The accessible test points and side stackable design allow for flexible PCB layout and maintenance. M2 clamping screws ensure a solid and reliable connection for each wire.

With a compact footprint measuring 14 mm in length, 8.5 mm in width, and 7.2 mm in depth, this grey terminal block fits well into space-restricted enclosures and electronic modules. Its compliance with CSA and VDE standards guarantees performance and safety in demanding environments.

Typical applications include industrial control panels, electronic assemblies, automation systems, and PCB mounting solutions where secure and precise connectivity is required.
