Wieland PCB Terminal Block 6-Contact 3.5mm Pitch Wave Soldering Mount 1 Row 10A 25.195.0653.0
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 300V |
| Brand | Wieland |
| Colour | Grey |
| Orientation | Straight |
| Current | 10A |
| Length | 21mm |
| Depth | 7.2mm |
| Width | 8.5mm |
| Mount Type | Wave Soldering Mount |
| Series | 8593 |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Standards/Approvals | CSA, VDE |
| Number of Contacts | 6 |
| Minimum Wire Size mm² | 0.14mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 16AWG |
| Test Points | Accessible |
Key Features
- Designed for PCB mounting with a reliable wave soldering footprint.
- Accommodates up to 6 independent contact circuits.
- Supports wire sizes from 0.14mm² up to 1.5mm² or 30AWG to 16AWG.
- Rated for continuous operation up to 10A and 300V.
- Nickel-plated brass terminal bodies with tinned bronze contact clamps ensure robust electrical performance.
- Features M2 nickel-plated galvanised steel clamping screws for secure wire connections.
- Certified to CSA and VDE standards for international compliance.
- Grey colour for conventional PCB component identification.
Product Description
The Wieland 25.195.0653.0 PCB Terminal Block is a high-quality connector designed for reliable electrical connections on printed circuit boards. This terminal block offers 6 contacts arranged in a single row, with a compact 3.5mm pitch, making it ideal for situations where space efficiency and robust performance are necessary.
With support for wave soldering, this block integrates seamlessly into standard automated assembly processes, ensuring secure and repeatable mounting. Its orientation is straight, simplifying the layout and routing for PCB designers.
It handles wire sizes as small as 0.14mm² and as large as 1.5mm², equivalent to 30AWG to 16AWG, thereby accommodating a wide range of wiring requirements. Maximum operating current is rated at 10A, with a voltage limit of 300V, making it suitable for power and signal applications in diverse electronic assemblies.
The terminal bodies are constructed from nickel-plated brass for conductivity and corrosion resistance, while the contact clamps are made of tinned bronze. Tightening screws are nickel-plated galvanised steel, offering durability and dependable contact pressure. It utilises M2 screws for easy assembly and secure wire fastening.
Accessible test points are present for straightforward diagnostic procedures during maintenance or board troubleshooting. Side stacking is possible via interlocking, facilitating modular PCB terminal layouts and expansion as needed.
Compact dimensions (length: 21mm, width: 8.5mm, depth: 7.2mm) ensure efficient use of board space. The grey colour aids conventional component identification on the PCB.
The product meets CSA and VDE safety and performance standards, allowing its use in international industrial and electronic environments. Primary use cases include industrial controls, automation systems, instrumentation, HVAC equipment, and modern manufacturing electronics where secure and standard-compliant PCB connections are essential.
Wieland PCB terminal blocks are trusted worldwide for their quality and compliance, making this model a safe and dependable choice for professional PCB assembly. Browse other PCB Terminal Blocks and connectors in the Electronics & Electricals category for a range of Wieland and other brands on EnvMart.
