RS PRO PCB Terminal Block 8-Contact, 5.08 mm Pitch, Through Hole, 1 Row 146-8264
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 300V |
| Brand | RS PRO |
| Colour | Green |
| Orientation | Vertical |
| Current | 10A |
| Length | 40.64mm |
| Model | 146-8264 |
| Depth | 10.1mm |
| Width | 8.3mm |
| Mount Type | Through Hole |
| Housing Material | Polyamide 66 |
| Series | RS PRO |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | RoHS, cRUus approved |
| Number of Contacts | 8 |
| Minimum Wire Size mm² | 0.13mm² |
| Maximum Wire Size mm² | 1.31mm² |
| Minimum Wire Size AWG | 26AWG |
| Maximum Wire Size AWG | 16AWG |
Key Features
- This terminal block supports 8 contacts for multiple wire connections.
- Features a pitch of 5.08 mm for standard spacing on PCBs.
- Constructed with green polyamide 66 housing for flame retardant properties.
- Mounted through hole to ensure solid mechanical and electrical connection.
- Compatible with wire sizes from 0.13 mm² to 1.31 mm² and AWG 26 to 16.
- Rated for a current capacity of 10 A and voltage limit of 300 V.
- Includes professional rising clamp terminals and guided pin alignment for ease of installation.
- Vertical orientation and a compact size measuring 40.64 mm length, 8.3 mm width, and 10.1 mm depth.
Product Description
RS PRO 146-8264 PCB Terminal Block is an 8-contact connector designed for through-hole mounting with a 5.08 mm pitch between contacts. Featuring a single-row layout, it is constructed from durable polyamide 66 housing, molded green with UL94-V0 flame retardant rating, ensuring operational safety and resistance to harsh industrial environments.
This terminal block supports wire sizes ranging from 0.13 mm² (26 AWG) up to 1.31 mm² (16 AWG), carrying a maximum current of 10 A and tolerating voltages up to 300 V. The professional rising clamp terminals provide secure connections, complemented by guided pin alignment and a captive screw mechanism for easy and reliable installation on printed circuit boards.
The compact vertical orientation design measures 40.64 mm in length, 8.3 mm in width, and 10.1 mm in depth, making it suitable for tight PCB layouts. It complies with RoHS environmental standards and carries cRUus approval, confirming its reliability and safety in demanding electrical and electronic applications.
Common industrial use cases include PCB terminal connection in electronics manufacturing, power connectors for industrial control systems, and equipment requiring stable and safe electrical signal and power distribution. The product is assembled in China and meets the RS PRO series standards recognized globally for quality and performance.
This terminal block supports 8 contacts for multiple wire connections. Features a pitch of 5.08 mm for standard spacing on PCBs. Constructed with green polyamide 66 housing for flame retardant properties. Mounted through hole to ensure solid mechanical and electrical connection.
Compatible with wire sizes from 0.13 mm² to 1.31 mm² and AWG 26 to 16. Rated for a current capacity of 10 A and voltage limit of 300 V. Includes professional rising clamp terminals and guided pin alignment for ease of installation.
Vertical orientation and a compact size measuring 40.64 mm length, 8.3 mm width, and 10.1 mm depth. Meets RoHS and cRUus approvals, ensuring compliance with environmental and safety standards. Ideal for industrial and commercial PCB connector applications requiring durability and reliability.
Explore more RS PRO PCB Terminal Blocks and related electronic components on EnvMart for reliable industrial-grade connections and solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for a maximum current capacity of 10 A.
The voltage limit for this terminal block is 300 V.
It is compatible with wire sizes ranging from 0.13 mm² (26 AWG) to 1.31 mm² (16 AWG).
The pitch between the contacts is 5.08 mm.
The terminal block measures 40.64 mm in length, 8.3 mm in width, and 10.1 mm in depth.
The housing is constructed from polyamide 66, which has flame retardant properties.
It is designed for through-hole mounting, ensuring a solid mechanical and electrical connection.
It complies with RoHS environmental standards and carries cRUus approval.
The terminal block is designed with a vertical orientation.
This model supports 8 contacts for multiple wire connections.
It includes professional rising clamp terminals and guided pin alignment for ease of installation.
The terminal block is assembled in China.
