Molex KK 396 Series Straight Through Hole Pin Header, 9 Contacts, 3.96 mm Pitch, 1 Row, Unshrouded 26-48-1095
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | KK 396 |
| Termination Type | Solder |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Tin |
| Number of Contacts | 9 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 4.37mm |
Key Features
- The pin header features a straight orientation ideal for through-hole mounting applications.
- Contacts are made of brass with tin plating ensuring reliable conductivity and corrosion resistance.
- The dielectric housing is constructed from durable polyester for enhanced insulation and stability.
- Suitable for voltages up to 250V and current ratings of 7 amps, supporting robust circuit requirements.
- Operating temperature range spans from -40°C to 80°C making it reliable for various environmental conditions.
- Termination type is solder, compatible with standard PCB assembly techniques.
- The design includes a 4.37 mm tail pin length facilitating secure mechanical and electrical connection.
- This pin header mates with a range of Molex housings and connectors, enhancing system modularity.
Product Description
Molex 26-48-1095 KK 396 Series Straight Through Hole Pin Header is a high-quality wire-to-board connector component designed for electronic and electrical applications. It features 9 contacts arranged in a single row with an unshrouded layout and a standard 3.96 mm pitch that ensures precise and reliable insertion into printed circuit boards.
Manufactured with brass contacts plated with tin, this pin header assures excellent electrical conductivity and protection against corrosion. The polyester housing provides robust insulation and mechanical stability, supporting long-term durability in industrial environments.
This component supports a continuous current rating of 7 amps and a maximum operating voltage of 250 volts, which is suitable for a wide array of electronic circuitry in industrial, laboratory, and manufacturing equipment. The operating temperature range from -40°C up to 80°C allows usage in harsh environmental conditions.
The tail pins measure 4.37 mm in length, designed for through-hole soldering to PCBs, ensuring secure fixation and reliable electrical connections for complex assemblies.
This pin header is compatible with Molex KK series housings and connectors, including series 3069, 2139, 6442, and 41695, as well as IDT connectors of series 7674 and 7675. Its unshrouded design facilitates visual inspection during manufacturing and easy troubleshooting and maintenance.
The pin header provides straight orientation with single row contact arrangement. Constructed with brass contacts and polyester housing for optimal performance. Suitable for wire-to-board connection systems in electronics and electrical devices.
Supports a voltage of 250 volts and current rating of 7 amps. Operates reliably from -40°C to 80°C industrial environments. Facilitates solder termination for durable PCB mountings. Mates with multiple compatible Molex and IDT series connectors and housings.
The 3.96 mm pitch maintains precise spacing for circuit layout standards.
This extensive compatibility and robust design make the Molex KK 396 series pin header an essential component for industrial, electronic manufacturing, automation, and electrical equipment applications. It supports assembly efficiency and high reliability in demanding technical environments.
Browse more high-quality PCB Headers and connectors in EnvMart's Electronics & Electricals category for integrated solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this pin header is 250V.
This model has a current rating of 7 amps.
The pitch of the contacts is 3.96 mm.
The contacts are made of brass with tin plating, and the housing is constructed from polyester.
The operating temperature range spans from -40°C to 80°C.
The tail pins measure 4.37 mm in length.
This model uses solder termination for PCB mounting.
Yes, this pin header is designed for through-hole mounting applications.
This pin header features 9 contacts arranged in a single row.
The orientation of this pin header is straight.
It is compatible with a range of Molex housings and connectors, including series 3069, 2139, 6442, and 41695, as well as IDT connectors of series 7674 and 7675.
The country of origin for this pin header is India.
