| Country of Origin | India |
|---|---|
| Brand | Infineon |
| Height | 800μm |
| Length | 2mm |
| Model | BSS816NWH6327XTSA1 |
| Width | 1.25mm |
| Mount Type | Surface |
| Series | OptiMOS 2 |
| Maximum Operating Temperature | 175°C |
| Package Type | SC-70 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Channel Type | N |
| Maximum Continuous Drain Current Id | 1.4A |
| Maximum Drain Source Voltage Vds | 20V |
| Maximum Drain Source Resistance Rds | 240mΩ |
| Channel Mode | Enhancement |
| Maximum Power Dissipation Pd | 500mW |
| Typical Gate Charge Qg @ Vgs | 0.6nC |
| Maximum Gate Source Voltage Vgs | -8, +8V |
| Forward Voltage Vf | 1.1V |
Infineon BSS816NWH6327XTSA1 is an OptiMOS 2 Series N-Channel Enhancement Mode MOSFET designed for low-voltage switching in automotive and industrial electronic systems. It features a maximum continuous drain current of 1.4 A and a maximum drain-source voltage of 20 V, packaged in a compact 3-pin SC-70 surface-mount form factor.
This device offers a low on-resistance of 240 milliohms which significantly reduces conduction losses and heat dissipation, enabling energy-efficient performance. The 500 milliwatt maximum power dissipation permits stable operation under light loads.
Operating temperatures range from -40°C to 175°C, making it suitable for harsh environments such as under-the-hood automotive locations. The typical gate charge of 0.6 nC facilitates rapid switching with reduced switching losses, improving efficiency in systems with frequent transitions. The gate-source voltage limit of ±8 V ensures protection against excessive voltages.
The SC-70 surface-mount package minimizes PCB area usage and supports automated assembly for high-density board designs. This MOSFET complies with the AEC-Q101 automotive standard, assuring quality and robustness for automotive applications.
Applications include switch stages in automotive sensor modules, load switching in 12 V auxiliary circuits, battery management peripherals, motor-drive gate stages for low current, and signal-level power control in infotainment systems.
Low on-resistance reduces conduction losses. Compact surface-mount SC-70 package. Wide temperature range for automotive environments. Fast switching with low gate charge. Protective gate-source voltage limits. Automotive grade AEC-Q101 compliance.
Suitable for sensor modules, load switching, and motor control. Optimized for high-density board layouts. Explore more semiconductor and MOSFET products at EnvMart for industrial, automotive, and electronic manufacturing solutions.
