Infineon 1 MB SPI FRAM Memory 8-Pin SOIC, 128K x 8 bit Organisation, 40MHz Maximum Clock Frequency FM25V10-G

Free Delivery in India | Lowest Global Shipping Charges

Infineon 1 MB SPI FRAM Memory 8-Pin SOIC, 128K x 8 bit Organisation, 40MHz Maximum Clock Frequency FM25V10-G

Name: Infineon 1 MB SPI FRAM Memory 8-Pin SOIC, 128K x 8 bit Organisation, 40MHz Maximum Clock Frequency FM25V10-G
Brand: Infineon
SKU: 194845
Price: 16.47 USD
Availability: InStock



Category Memory Chips Brand Infineon Condition New

Specifications

Country of Origin	United States
Brand	Infineon
Height	1.47mm
Length	4.97mm
Model	FM25V10-G
Width	3.98mm
Mount Type	Surface
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Memory size	1MB
Interface Type	SPI
Pin Count	8
Automotive Standard	AEC-Q100
Maximum Supply Voltage	3.6V
Minimum Supply Voltage	2V
Maximum Clock Frequency	40MHz
Organisation	128K x 8 bit
Number of Bits per Word	8
Maximum Random Access Time	18ns
Number of Words	128k

Key Features

Features a 1 Mbit memory size organised as 128K x 8 bit for efficient data handling.
Supports SPI interface with a maximum clock frequency of 40 MHz for rapid memory access.
Compact surface mount SOIC package with 8 pins, dimensions 4.97mm x 3.98mm x 1.47mm.
Provides fast write operations with no delay and advanced write protection for data integrity.
Operates over a temperature range from -40°C to 85°C, compliant with automotive standard AEC-Q100.
Designed for use in automotive control systems, industrial automation, medical devices, consumer electronics and IoT applications.
Low power consumption with 300 μA active current and 5 μA sleep current suitable for battery-powered devices.

Product Description

Infineon FM25V10-G is a 1 MB SPI FRAM Memory device housed in a compact 8-pin SOIC surface mount package measuring 4.97mm in length, 3.98mm in width, and 1.47mm in height. This product offers 128K x 8 bit memory organisation, providing non-volatile, high-speed memory storage solutions for a range of electronic applications.

The FM25V10-G supports a high maximum clock frequency of 40 MHz via an SPI interface, ensuring rapid data access and efficient performance for applications requiring fast write operations without delays. Its advanced write protection features safeguard against accidental data alterations, essential in mission-critical systems.

Operating within the temperature range of -40°C to 85°C and complying with the automotive AEC-Q100 standard, it is well-suited for environments including automotive control systems, industrial automation processes, medical instrumentation, consumer electronics, and IoT devices.

Power efficiency is a key attribute, with active operation current of 300 μA and an ultra-low sleep current of 5 μA, making it ideal for battery-operated devices and energy-conscious designs.

Features a 1 Mbit memory size organised as 128K x 8 bit. High-speed SPI interface with up to 40 MHz clock frequency. Compact SOIC package with 8 pins facilitates easy surface mounting. Advanced write protection mechanisms to ensure data safety.

Wide operating temperature range (-40°C to 85°C) suitable for automotive applications. Automotive standard compliant (AEC-Q100) ensuring robustness. Low power consumption optimized for portable and industrial electronics.

This memory chip is an ideal choice for industrial, automotive, medical, and consumer electronic applications where rapid, reliable, and energy-efficient non-volatile memory is required. It enables enhanced data logging and fast data retention for embedded systems.
