Molex C-Grid III Series Straight Through Hole Pin Header 18 Contacts 2.54 mm Pitch 1 Row Unshrouded 90120-0778

Free Delivery in India | Lowest Global Shipping Charges

Molex C-Grid III Series Straight Through Hole Pin Header 18 Contacts 2.54 mm Pitch 1 Row Unshrouded 90120-0778

Name: Molex C-Grid III Series Straight Through Hole Pin Header 18 Contacts 2.54 mm Pitch 1 Row Unshrouded 90120-0778
Brand: Molex
SKU: 207023
Price: 3.27 USD
Availability: InStock



Category PCB Header Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	350V
Brand	Molex
Orientation	Straight
Current	3A
Mount Type	Through Hole
Housing Material	Polyester
Contact Material	Brass
Series	C-Grid III
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	18
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board
Tail Pin Length	2.9mm
Mating Pin Length	6.75mm

Key Features

Designed for wire-to-board connections with a 2.54 mm pitch for precise PCB interfacing.
Features 18 male brass contacts with gold plating ensuring durable conductivity.
Unshrouded single-row configuration allows for flexible circuit design.
Through hole mounting type provides secure and stable PCB installation.
Operates safely up to 350V and a current rating of 3A.
Temperature range from -55°C to 125°C suitable for harsh operating environments.
Breakaway design for cutting to size, enabling customization to project needs.
High retention force contacts ensure secure mating and high mechanical stability once soldered.

Product Description

Molex 90120-0778 C-Grid III Series straight through hole pin header is a precision-designed PCB component with 18 unshrouded male contacts arranged in a single row with 2.54 mm pitch. It facilitates reliable wire-to-board connections and meets industry requirements for electrical and mechanical robustness.

This pin header uses brass contacts plated with gold for excellent conductivity, corrosion resistance, and durability under repeated mating cycles. The through hole mounting type ensures firm attachment to the PCB and superior mechanical stability.

Operating voltage up to 350V and current rating of 3A make it suitable for varied electronic assemblies including industrial machines, computer servers, medical instrumentation, consumer electronics, telecommunications equipment, and automotive safety electronics.

The headers feature a breakaway design allowing engineers to cut the component to required sizes, thus offering design flexibility without compromising connection integrity. The unshrouded configuration is suited for applications requiring broad accessibility to pins.

With operating temperature tolerances from -55°C to 125°C, this pin header performs reliably in harsh environments. The high retention force of the pins ensures a secure and stable connection, instrumental in maintaining system performance.

Wire-to-board connector system designed for PCB mounting. Unshrouded male contacts configured in a single row. Gold plated brass contacts for enhanced durability and conductivity. Breakaway design offers customization and design flexibility.

Suitable for industries including industrial automation, computer, medical, telecommunications, and automotive sectors. Stocked and referenced under RS stock no. 670-5091P, this component is ideal for engineers and designers requiring dependable PCB pins for professional assemblies.

Explore additional Molex PCB components and headers in our electronics catalog for complementary connectors and accessories, ensuring comprehensive interconnection solutions at EnvMart.

Explore more products in our PCB Header category.
