Molex 1.25 mm Pitch 5 Way Right Angle Female FPC Connector, Through Hole, Solder Termination, Series 5597, Model 39-53-2054
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 200V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 1A |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | 5597 |
| Termination Type | Solder |
| Maximum Operating Temperature | 80°C |
| Sub Type | Easy-On FFC/FPC Connector |
| Minimum Operating Temperature | -20°C |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| Contact Plating | Tin Bismuth over Nickel |
| Number of Contacts | 5 |
| Contact Gender | Female |
| Connector Gender | Female |
| Insertion Force | ZIF |
Key Features
- Features a zero insertion force (ZIF) slide type actuator for secure FPC connection.
- Constructed with phosphor bronze contacts plated with tin bismuth over nickel.
- Housing made from durable polybutylene terephthalate (PBT) material.
- Operates at up to 200 V and 1 A current rating.
- Designed to withstand temperatures from -20°C to 80°C for automotive and electronic applications.
- Includes locking mechanism for reliable connection retention.
- Single row, 5 contacts for compact space-saving design.
- Manufactured in Japan, ensuring quality and reliability.
Product Description
Molex 39-53-2054 is a high-quality 5 way right angle female FPC connector with a 1.25 mm pitch, featuring zero insertion force (ZIF) design optimized for through hole PCB mounting and solder termination. This connector is part of the 5597 series designed for tight packaging applications requiring reliable and easy-to-install FPC connections.
The connector contacts are made of phosphor bronze with tin bismuth over nickel plating to ensure excellent conductivity and corrosion resistance. The housing is constructed from polybutylene terephthalate (PBT), providing mechanical strength and stability under operating conditions ranging from -20°C to 80°C. The device supports voltage up to 200 V and current up to 1 A, making it suitable for various electronic and automotive assemblies.
This connector includes a slide type actuator that allows for secure locking with minimal wear over repeated insertion cycles. Its right angle orientation facilitates space-saving design on PCBs while maintaining secure contact retention thanks to the built-in locking mechanism. The connector has a single row with 5 contacts, providing compact and efficient connection capability.
Molex 39-53-2054 connectors are ideal for use in automotive electronics, communication devices, consumer electronics, and industrial control systems. Their reliable performance and high-quality construction ensure consistent operation in demanding environments.
Zero insertion force (ZIF) design for easy FPC insertion and removal. Slide type actuator ensures secure and lasting connections. Phosphor bronze contacts with tin bismuth over nickel plating. PBT housing for durability under wide temperature ranges.
Right angle orientation optimizes PCB layout and space utilization. Supports voltages up to 200 V and currents up to 1 A. Includes locking mechanism for connection reliability. Manufactured in Japan with stringent quality standards.
Explore the Electronics Components and FPC Connectors category at EnvMart for additional high-performance connectors and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a voltage of up to 200 V and a current rating of 1 A.
The pitch size of this connector is 1.25 mm.
The contacts are made of phosphor bronze with tin bismuth over nickel plating, while the housing is constructed from polybutylene terephthalate (PBT).
It operates within a temperature range of -20°C to 80°C.
This connector features 5 contacts in a single row design.
It uses solder termination for secure connections.
The connector has a right angle orientation, which is designed for space-saving on PCBs.
This model features a zero insertion force (ZIF) design, allowing for easy insertion and removal of the FPC.
It is manufactured in Japan, ensuring adherence to quality standards.
It is suitable for automotive electronics, communication devices, consumer electronics, and industrial control systems.
Yes, it includes a locking mechanism to ensure reliable connection retention.
This connector is part of the 5597 series, designed for tight packaging applications requiring reliable FPC connections.
