Molex Milli-Grid Series Straight Surface PCB Header, 8 Contact, 2 mm Pitch, 2 Row, Shrouded 87832-0820

Free Delivery in India | Lowest Global Shipping Charges

Molex Milli-Grid Series Straight Surface PCB Header, 8 Contact, 2 mm Pitch, 2 Row, Shrouded 87832-0820

Name: Molex Milli-Grid Series Straight Surface PCB Header, 8 Contact, 2 mm Pitch, 2 Row, Shrouded 87832-0820
Brand: Molex
SKU: 206296
Price: 1.67 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	125V
Brand	Molex
Orientation	Straight
Current	2A
Mount Type	Surface
Housing Material	Nylon
Contact Material	Phosphor Bronze
Series	Milli-Grid
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2mm
Contact Plating	Gold
Number of Contacts	8
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	2.5mm
Mating Pin Length	2mm

Key Features

Designed with a 2 mm pitch and 2 rows for high-density PCB applications.
Constructed with a nylon housing ensuring robust insulation and durability.
Features gold-plated phosphor bronze contacts for reliable electrical performance.
Supports a maximum operating temperature of 105°C and minimum of -55°C for extended use.
Suitable for wire-to-board connection systems with a surface mount type.
Contact gender is male with solder termination type for ease of assembly.
Contacts rated for 2 A current with a voltage rating of 125 V.
Includes tail pin length of 2.5 mm and mating pin length of 2 mm for secure connections.

Product Description

Molex 87832-0820 Milli-Grid Series Straight Surface PCB Header is a high-density connector designed for reliable wire-to-board applications with 8 contacts arranged in 2 rows and a 2 mm pitch. This shrouded header features a durable nylon housing and gold-plated phosphor bronze contacts to provide excellent electrical conductivity and resistance to corrosion.

The connector supports operating temperatures ranging from -55°C to 105°C, making it suitable for a wide range of industrial, electronic, and manufacturing environments. Its surface mount type and solder termination enable straightforward PCB assembly and secure mechanical stability.

Contact specifications include a male contact gender, with tail pin length of 2.5 mm and mating pin length of 2 mm, designed to mate with corresponding 51110 Series receptacles. The 2A current rating and 125 V voltage rating meet typical requirements for power and signal integrity in PCB assemblies.

The Milli-Grid system offers a 2.0 mm grid pattern for flexible board-to-board and cable-to-board interconnections, commonly used in electronic equipment manufacturing, testing setups, and industrial control devices.

Designed with a 2 mm pitch and 2 rows for high-density PCB applications. Constructed with a nylon housing ensuring robust insulation and durability. Features gold-plated phosphor bronze contacts for reliable electrical performance.

Supports a maximum operating temperature of 105°C and minimum of -55°C for extended use. Suitable for wire-to-board connection systems with a surface mount type. Contact gender is male with solder termination type for ease of assembly.

Contacts rated for 2 A current with a voltage rating of 125 V. Includes tail pin length of 2.5 mm and mating pin length of 2 mm for secure connections.

This PCB header is ideal for the electronics industry, including applications in industrial, communication, consumer electronics, and medical device manufacturing. The product ensures precision and durability required for professional and laboratory electrical setups.
