onsemi NPN Bipolar Transistor 200 mA 40 V 3-Pin SOT-23 MMBT3904LT1G

onsemi MMBT3904LT1G is a high-quality NPN bipolar transistor designed for general-purpose switching and amplification in electronic circuits. It features a maximum DC collector current of 200 mA and a collector-emitter voltage rating of 40 V, making it suitable for low to moderate power applications.

Housed in a compact 3-pin SOT-23 surface-mount package, the transistor offers space-efficient design conforming to modern PCB assembly standards. Its small dimensions of 3.04 mm (length), 2.64 mm (height), and 1.11 mm (width) facilitate dense circuit designs.

This transistor operates efficiently up to a maximum power dissipation of 300 mW and supports a broad temperature range from -55°C to 150°C, allowing excellent reliability in varying environmental conditions. Its high transition frequency of 300 MHz ensures fast switching suitable for signal amplification and high-speed applications.

The device complies with the automotive AEC-Q101 standard, reflecting its suitability for automotive electronic circuits requiring stringent quality and reliability measures.

The onsemi MMBT3904LT1G transistor is ideal for use in industrial, automotive, consumer electronics, and HVAC control systems where reliable small-signal amplification or switching is required.

Supports a maximum DC collector current of 200 mA for moderate current applications. Maximum collector-emitter voltage rating of 40 V ensures reliable switching performance. Single transistor configuration with NPN polarity suitable for general-purpose use.

Compact SOT-23 surface-mount package with dimensions 3.04 mm length, 2.64 mm height, and 1.11 mm width. High transition frequency of 300 MHz for high-speed switching and amplification. Wide operating temperature range from -55°C to 150°C for diverse environmental conditions.

Maximum power dissipation of 300 mW allows safe operation in low-power circuits. Complies with automotive standard AEC-Q101 ensuring reliability in automotive applications. Explore onsemi Bipolar Transistors and other semiconductor products in the EnvMart Electronics & Electricals category for industrial and commercial use.
