Samtec TFM Series Straight Surface PCB Header 10 Contacts 1.27 mm Pitch 2 Row Shrouded TFM-105-02-L-D-WT

Samtec TFM-105-02-L-D-WT is a new, high-quality PCB header from the TFM Series featuring a straight, shrouded surface mount design with 10 contacts arranged in 2 rows. It has a pitch of 1.27 mm, making it ideal for precise board-to-board and wire-to-board connections in industrial, electronics manufacturing, and telecommunications applications.

The housing material is liquid crystal polymer, delivering excellent durability and thermal stability within an operating temperature range from -55°C to 125°C. The contacts are made of phosphor bronze, plated with gold to ensure reliable electrical conductivity and corrosion resistance. This male connector supports up to 3.2A current at 250V voltage, offering robust performance in demanding environments.

This rugged component supports both through-hole and surface mount solder terminations and includes special rugged options such as screw down, weld tab, and solder nail to meet rigorous industrial requirements. The shrouded body design enables blind mating, improving assembly efficiency and contact protection. Its vertical straight orientation and multiple stack heights enable versatile mechanical and electrical configurations.

Liquid crystal polymer housing provides mechanical strength and heat resistance. Gold-plated phosphor bronze contact material ensures reliable conductivity. Operating temperature range from -55°C to 125°C suits harsh environments.

Supports 3.2A current at 250V for industrial electronics use. Shrouded design allows for secure blind mating protection. Available with screw down and weld tab options for rugged mounting. Two rows of contacts spaced at 1.27 mm pitch enable compact footprint.

Surface mount and through-hole termination types increase application flexibility. Male contact gender suitable for mating with Tiger Eye contact sockets and cable assemblies. Manufactured in the United States for assured quality and compliance.

This PCB Header is suitable for electronics manufacturing industries requiring durable, high-reliability connectors. It is ideal for board-to-board, wire-to-board applications, and is compatible with high-cycle, high-reliability mating assemblies. Whether used in telecommunications equipment, industrial controls, or high-performance computing systems, the Samtec TFM Series delivers proven performance and design flexibility.
