Samtec 0.5 mm Pitch 10 Way Right Angle Female PCB Socket Surface Mount Solder ZF5S

Samtec ZF5S model is a high-precision 0.5 mm pitch PCB socket connector designed for reliable electronic interconnections in industrial, manufacturing, and laboratory PCB assemblies. It features 10 female contacts constructed from phosphor bronze, offering excellent electrical conductivity and mechanical stability. The connector supports a current rating of 1.8A, making it suitable for medium power circuit applications where compact size and electrical reliability are essential.

This ZF5S series socket utilizes a Zero Insertion Force (ZIF) mechanism, minimizing wear and tear on both the connector and cable during insertion and removal, thereby extending lifecycle in demanding environments. Its right angle orientation facilitates efficient PCB layout designs by allowing cables to exit parallel to the board surface.

The connector housing is made from natural Liquid Crystal Polymer (LCP), known for its high strength, thermal stability, and resistance to chemicals, enabling operation in harsh industrial conditions. Contact surfaces are plated with tin over nickel, offering corrosion resistance and stable conductivity over extended use.

Rated for operation between -55°C and 105°C, this PCB socket is engineered for use in environments ranging from cold storage facilities to high heat production lines. Its surface mount termination type ensures a secure solder joint to the PCB, enhancing mechanical retention and signal integrity.

The locking mechanism integrated into the design provides positive retention for flat flexible cables (FFC) or flat printed cables (FPC), preventing accidental disconnections during operation or handling.

Features 10 contacts with phosphor bronze material for excellent conductivity. Supports 1.8A current rating suitable for medium power applications. Zero Insertion Force (ZIF) connector facilitates easy insertion and removal.

Right angle orientation optimizes PCB layout space. Constructed with natural LCP housing ensuring high mechanical strength. Contact plating consists of tin over nickel for corrosion resistance. Operating temperature range from -55°C to 105°C for wide environment compatibility.

Connector includes locking mechanism for secure cable retention. Designed for surface mount solder termination offering robust mechanical connection.

This Samtec ZF5S PCB Socket is ideal for applications in electronics manufacturing, industrial automation, telecommunications, and laboratory equipment where compact, durable, and reliable PCB connectors are essential. Discover more from our Electronics & Electricals collection at EnvMart for professional-grade connectors and components.
