Samtec SSW Series PCB Socket 10-Contact 2 Row 2.54 mm Pitch Through Hole Solder Straight SSW-105-01-T-D

The Samtec SSW-105-01-T-D is a precision-engineered PCB socket designed for demanding board-to-board connections in industrial, laboratory, and high-performance electronic systems. Featuring 10 contacts and a dual-row configuration, it is specifically tailored for applications requiring reliable connectivity and robust construction.

This socket utilizes a through-hole mounting style and a straight orientation, providing excellent stability and secure placement on printed circuit boards. Its 2.54 mm pitch allows for easy integration with standard headers and meets widespread industry requirements.

Constructed with a liquid crystal polymer housing, the SSW Series offers enhanced thermal resistance and mechanical durability. The contacts are made from bronze with tin plating and feature the proprietary Tiger Buy™ system, which provides both standard and low insertion force for optimal mating and unmating cycles. The socket supports operating voltages up to 655 V and currents up to 6.3 A, making it suitable for a wide range of industrial and commercial electronics.

Designed to function across an extensive temperature range of -55°C to 105°C, the SSW-105-01-T-D meets reliability standards required for mission-critical environments. Its female contacts and a solder termination ensure excellent electrical performance and easy assembly during manufacturing, prototyping, or PCB repair operations.

Common applications include use in control systems, instrumentation, automation interfaces, and electronic development boards. The compact 10-contact, 2-row configuration is ideal for electronic devices where space-saving and dependable functionality are essential. With its high retention contacts and rugged housing, this socket is well-suited for both commercial and industrial PCB designs.

The Samtec SSW-105-01-T-D PCB Socket can be browsed under PCB Socket and Electronics & Electricals categories for more board-to-board connector options, featuring superior build quality and technical versatility for diverse environments.
