| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.1mm |
| Length | 1.8mm |
| Model | BAT54WS-7-F |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | BAT54WS |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 200mA |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 2μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 600mA |
| Maximum Forward Voltage Vf | 1V |
| Peak Reverse Recovery Time trr | 5ns |
DiodesZetex BAT54WS-7-F is a high-performance Schottky switching diode with a maximum continuous forward current of 200 mA and peak repetitive voltage of 30 V. Housed in a compact surface mount SOD-323 package with a 2-pin configuration, it offers a maximum forward voltage of 1 V and ultra-fast reverse recovery time of 5 ns, making it ideal for applications requiring rapid switching and low voltage drop.
Designed to operate reliably across a wide temperature range from -65°C to 150°C, this diode suits various industrial, automotive, and consumer electronics applications. Its low peak reverse current of 2 μA contributes to energy efficiency and reduced leakage currents in circuits. Compliance with the automotive standard AEC-Q101 ensures robust quality and durability for automotive electronics.
The device’s compact size with dimensions of 1.8 mm length, 1.4 mm width, and 1.1 mm height enables space-saving PCB layouts in modern electronic designs. The BAT54WS series represents next-generation super barrier rectifiers characterized by lower forward voltage than comparable Schottky diodes, while maintaining the thermal stability and reliability associated with PN epitaxial diodes.
Maximum continuous forward current is 200 mA. Peak reverse repetitive voltage rated at 30 V. Forward voltage maximum of 1 V for efficient switching. Operating temperature range from -65°C to 150°C. Low peak reverse current of 2 μA.
Fast peak reverse recovery time of 5 ns. Compact SOD-323 package dimensions. Single diode configuration. Automotive grade AEC-Q101 standard. Manufactured in China.
This Schottky diode is widely applicable in semiconductor switching circuits, power management, and automotive electronics. The efficient performance parameters make it well-suited for industrial automation, consumer electronics, and telecommunications equipment.
Explore more Schottky Diodes and semiconductor components in the EnvMart Electronics & Electricals category for advanced semiconductor solutions tailored to demanding industrial and commercial uses.
