DiodesZetex Schottky Rectifier Diode 40V 1A SOD-323 Surface Mount ZHCS400TA
Specifications
| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.05mm |
| Length | 1.8mm |
| Model | ZHCS400TA |
| Width | 1.45mm |
| Mount Type | Surface |
| Series | ZHCS400X |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | FBI |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 40μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 6.75A |
| Maximum Forward Voltage Vf | 500mV |
Key Features
- 40V peak reverse repetitive voltage rating provides robust protection in electronic circuits.
- Maximum continuous forward current of 1A suitable for low- to medium-power rectification applications.
- Schottky rectifier construction offers lower forward voltage and fast switching performance.
- Surface mount SOD-323 package enables compact PCB designs and automated assembly.
- Wide operating temperature from -55°C to 150°C ensures reliability in automotive and industrial environments.
- Meets AEC-Q101 automotive standard for enhanced quality.
- Very low peak reverse current of 40μA for efficient operation.
- Two-pin configuration simplifies integration into circuit layouts.
Product Description
DiodesZetex ZHCS400TA is a high-reliability Schottky rectifier diode designed for use in electronic protection, power rectification, and switching circuits where low voltage drop and fast switching are required. This model operates at a maximum reverse repetitive voltage of 40V and allows a continuous forward current of up to 1A, making it suitable for a range of low- to medium-power applications.
With a SOD-323 surface mount package, the ZHCS400TA is optimized for PCB layouts where space saving and automated production are essential. The Schottky barrier construction delivers a low forward voltage (maximum 500mV at rated current), contributing to higher efficiency and reduced power losses compared to standard rectifiers.
The diode's fast switching capability is beneficial in circuits requiring quick response times, such as power supplies, voltage clamping, and reverse polarity protection. Its peak reverse current of only 40μA ensures minimal leakage, preserving circuit integrity and reliability.
The ZHCS400TA is automotive-grade, compliant with the AEC-Q101 standard, supporting its use in demanding environments including automotive, industrial, and commercial equipment. The extended operating temperature range from -55°C up to 150°C enables usage in harsh conditions.
Dimensionally, this diode measures 1.8mm in length, 1.45mm in width, and 1.05mm in height, reflecting its compact form factor ideal for densely populated PCBs. The two-pin configuration provides easy integration in rectifier circuits, protection networks, and voltage regulation modules.
40V rating ensures compatibility with typical circuit voltages for protection and rectification. 1A current capability supports powering small motors, sensors, and protection relays. Automotive-standard construction enables use in vehicle electronics and critical safety systems.
Reliable operation with minimum forward surge current of 6.75A for transient events. Ideal for industrial, automotive, consumer electronics, and commercial circuit designs.
For engineers looking for high efficiency, fast switching, and reliability in a compact diode package, the DiodesZetex ZHCS400TA is an excellent choice. Browse EnvMart’s Schottky Diode selection for more options from DiodesZetex and other leading brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum reverse repetitive voltage rating of the ZHCS400TA is 40V, providing robust protection in electronic circuits.
This model supports a maximum continuous forward current of 1A, making it suitable for low- to medium-power rectification applications.
The diode measures 1.8mm in length, 1.45mm in width, and 1.05mm in height, making it compact for PCB designs.
The peak reverse current for the ZHCS400TA is 40μA, ensuring efficient operation with minimal leakage.
The ZHCS400TA comes in a SOD-323 surface mount package, which is optimized for compact PCB layouts and automated assembly.
This model operates within a wide temperature range from -55°C to 150°C, ensuring reliability in various environments.
Yes, it meets the AEC-Q101 automotive standard, supporting its use in automotive applications and critical safety systems.
The maximum forward voltage at the rated current is 500mV, contributing to higher efficiency in circuit designs.
The ZHCS400TA has a two-pin configuration, simplifying integration into various circuit layouts.
This diode is suitable for electronic protection, power rectification, and switching circuits where low voltage drop and fast switching are required.
The peak non-repetitive forward surge current for the ZHCS400TA is 6.75A, which is important for handling transient events.
The ZHCS400TA is a Schottky rectifier, known for its lower forward voltage and fast switching performance.
