Vishay 1200 V 40 A Switching Diode 2-Pin DO-203AB VS-41HF120
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 17.4mm |
| Brand | Vishay |
| Height | 22.9mm |
| Length | 20.02mm |
| Model | VS-41HF120 |
| Width | 17.35mm |
| Mount Type | Screw |
| Series | VS |
| Maximum Operating Temperature | 190°C |
| Package Type | DO-203AB |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 40A |
| Peak Reverse Repetitive Voltage Vrrm | 1200V |
| Diode Configuration | Stud Cathode |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 9mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 595A |
| Maximum Forward Voltage Vf | 1.3V |
| Vishay 1200 V 40 A Diode Recovery 2-Pin DO-5Brand | Vishay |
Key Features
- Standard recovery power diode designed for switching applications.
- Stud cathode diode configuration ensures reliable conductivity.
- Compact DO-203AB package with dimensions optimized for circuit design.
- Operating temperature range from -65°C to 190°C supports diverse environments.
- Maximum forward voltage drop of 1.3 V enhances efficiency.
- High peak non-repetitive surge current of 595 A provides protection against transient loads.
- 2-pin package simplifies mounting and integration.
- Maximum peak reverse current of 9 mA minimizes leakage and power loss.
Product Description
Vishay VS-41HF120 switching diode is a high-efficiency, standard recovery power diode housed in a 2-pin DO-203AB package. Designed to handle a maximum continuous forward current of 40 A and a peak reverse repetitive voltage of 1200 V, it is ideal for industrial semiconductor and power electronics applications.
The diode features a stud cathode configuration and provides a maximum forward voltage drop of 1.3 V, ensuring efficient conduction with minimal losses. Its robust screw mounting type offers secure and reliable installation in demanding environments.
Operating over a wide temperature range from -65°C to 190°C, the VS-41HF120 is suitable for use in harsh industrial conditions. It supports transient loads with a high peak non-repetitive forward surge current rating of 595 A and maintains low leakage current with a maximum peak reverse current of 9 mA.
The physical dimensions include a height of 22.9 mm, length of 20.02 mm, width of 17.35 mm, and diameter of 17.4 mm, making it compact and suitable for varied PCB layouts. Standard recovery diode optimized for switching applications.
High surge current capability for transient protection. Wide operating temperature range for industrial use. Secure screw mount package for reliable integration. Compact DO-203AB form factor suitable for space-constrained designs.
Low forward voltage drop minimizes energy loss. Stud cathode configuration enhances conductivity. Ideal for power management and rectification in circuits.
This diode is extensively used in power supplies, automotive electronics, industrial circuit protection, and general semiconductor switching roles. Vishay's quality and reliability standards ensure long-lasting performance in critical applications.
Discover more Vishay semiconductor components and Switching Diodes on EnvMart for comprehensive industrial and electronic solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for the VS-41HF120 diode is 40 A.
This model has a peak reverse repetitive voltage rating of 1200 V.
The diode operates within a temperature range of -65°C to 190°C.
The maximum forward voltage drop for the VS-41HF120 is 1.3 V.
It features a stud cathode configuration, which enhances conductivity.
The peak non-repetitive forward surge current rating is 595 A.
The dimensions are as follows: height 22.9 mm, length 20.02 mm, width 17.35 mm, and diameter 17.4 mm.
This model uses a screw mounting type for secure installation.
The maximum peak reverse current is 9 mA, which helps minimize leakage and power loss.
The diode is housed in a DO-203AB package type.
It is commonly used in power supplies, automotive electronics, and industrial circuit protection.
The country of origin for the VS-41HF120 is India.
