Vishay 1-Element Uni-Directional TVS Diode Surface Mount DO-214AA Package 600 W Peak Pulse Power SMBJ6.0A-E3

Free Delivery in India | Lowest Global Shipping Charges

Vishay 1-Element Uni-Directional TVS Diode Surface Mount DO-214AA Package 600 W Peak Pulse Power SMBJ6.0A-E3

Name: Vishay 1-Element Uni-Directional TVS Diode Surface Mount DO-214AA Package 600 W Peak Pulse Power SMBJ6.0A-E3
Brand: Vishay
SKU: 201796
Price: 0.24 USD
Availability: InStock



Category TVS Diode Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	2.24mm
Length	4.57mm
Model	SMBJ6.0A-E3
Width	3.94mm
Mount Type	Surface
Series	TRANSZORB TVS
Maximum Operating Temperature	150°C
Package Type	DO-214AA (SMB)
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Clamping Voltage VC	10.3V
Automotive Standard	AEC-Q101
Diode Configuration	Single
Direction Type	Uni-Directional
Minimum Breakdown Voltage Vbr	6.67V
Maximum Reverse Stand-off Voltage Vwm	6V
Peak Pulse Power Dissipation Pppm	600W
Test Current It	10mA
Maximum Peak Pulse Current Ippm	58.3A
Maximum Reverse Leakage Current	800μA

Key Features

This diode features a single-element, uni-directional configuration for effective voltage transient protection.
The device offers a minimum breakdown voltage of 6.67 V and a maximum reverse stand-off voltage of 6 V.
It supports a maximum peak pulse current of 58.3 A with excellent clamping voltage of 10.3 V.
Designed for surface mounting, it measures 4.57 mm in length, 3.94 mm in width, and 2.24 mm in height.
The diode operates over a temperature range from -55°C to 150°C and complies with automotive standard AEC-Q101.
It has low incremental surge resistance and very fast response time for reliable electronics protection.
This TVS diode is ideal for protecting sensitive electronics against voltage transients in consumer, industrial, computer, and telecommunication applications.

Product Description

Vishay SMBJ6.0A-E3 is a 1-element uni-directional Transient Voltage Suppressor (TVS) diode designed for surface mounting in a compact DO-214AA package. It delivers 600 W peak pulse power dissipation, making it suitable for safeguarding electronic circuits from voltage spikes and transient overvoltages induced by inductive load switching or lightning events.

This TVS diode features a minimum breakdown voltage of 6.67 V and maximum reverse stand-off voltage of 6 V, ensuring precise clamping at a voltage of 10.3 V. Operating temperature range extends from -55°C up to 150°C, supporting demanding automotive and industrial environments as validated by compliance with the AEC-Q101 standard.

Measuring 4.57 mm in length, 3.94 mm in width, and 2.24 mm in height, the SMBJ6.0A-E3 comes in a low-profile surface mount package ideal for automated PCB assembly. It possesses fast response time, low incremental surge resistance, and excellent clamping capability, effectively protecting ICs, MOSFETs, sensors, and signal lines in consumer electronics, computing, industrial controls, and telecommunications.

Each diode includes ESD protection and is glass passivated for enhanced reliability. Its 2-pin configuration simplifies integration into circuits requiring transient suppression within a compact footprint.

Applications encompass transient voltage suppression for industrial machinery, HVAC equipment, computing devices, communication infrastructure, and automotive electronics where voltage spikes can cause damage or operational instability.

This diode features a single-element, uni-directional configuration for effective voltage transient protection. The device offers a minimum breakdown voltage of 6.67 V and a maximum reverse stand-off voltage of 6 V. It supports a maximum peak pulse current of 58.3 A with excellent clamping voltage of 10.3 V.

Designed for surface mounting, it measures 4.57 mm in length, 3.94 mm in width, and 2.24 mm in height. The diode operates over a temperature range from -55°C to 150°C and complies with automotive standard AEC-Q101. It has low incremental surge resistance and very fast response time for reliable electronics protection.

This TVS diode is ideal for protecting sensitive electronics against voltage transients in consumer, industrial, computer, and telecommunication applications. Explore Vishay TVS Diodes on EnvMart for industry-grade transient voltage protection solutions with assured quality and performance.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The diode has a peak pulse power dissipation of 600 W, making it suitable for protecting electronic circuits from voltage spikes.

It features a minimum breakdown voltage of 6.67 V, ensuring effective voltage transient protection.

The maximum reverse stand-off voltage is 6 V, allowing it to handle transient overvoltages safely.

The clamping voltage is 10.3 V, which helps to protect sensitive components from overvoltage conditions.

This model supports a maximum peak pulse current of 58.3 A, providing robust protection against voltage transients.

The diode operates over a temperature range from -55°C to 150°C, suitable for various environmental conditions.

It measures 4.57 mm in length, 3.94 mm in width, and 2.24 mm in height, making it compact for surface mounting.

This diode features a single-element configuration, designed for uni-directional voltage transient protection.

The diode is housed in a DO-214AA package type, suitable for surface mounting applications.

It complies with the automotive standard AEC-Q101, ensuring reliability in automotive applications.

The maximum reverse leakage current is 800 μA, which is important for ensuring low power loss during operation.

This TVS diode is ideal for protecting sensitive electronics in consumer, industrial, computer, and telecommunication applications against voltage transients.
