Nexperia Digital Transistor 500 mA NPN 50 V 3-Pin SOT-23 PDTD123YT,215

Nexperia PDTD123YT,215 digital transistor is an integrated resistor-equipped bipolar NPN transistor designed for direct digital signal handling. It supports up to 500 mA collector current and a maximum collector-emitter voltage of 50 V. Packaged in a compact 3-pin SOT-23 surface mount device, this transistor is ideal for efficient and reliable switching in electronic circuits.

The device incorporates one or two internal resistors, eliminating the need for external base resistors and simplifying design integration. It features a minimum DC current gain (hFE) of 70 and a maximum power dissipation rating of 250 mW, suitable for low power applications in automotive, industrial, and consumer electronics.

Operating temperature range from -55°C to 150°C ensures robust performance across harsh environments. Compliance with the AEC-Q101 automotive standard guarantees high quality and suitability for automotive electronic systems.

Typical applications include digital logic driving, switching circuits, signal amplification, and precise control in embedded systems. The small form factor and surface mount compatibility enable space-saving PCB layouts in modern electronic devices.

High-performance NPN transistor for digital switching. Internal resistors allow direct interfacing with digital sources. Maximum collector current of 500 mA supports varied load conditions. Compact 3-pin SOT-23 surface mount package.

Wide operating temperature from -55°C to 150°C. Power dissipation of 250 mW ensures stable operation. AEC-Q101 automotive standard compliant. Dimensions: 2.9 mm length, 0.94 mm width, 1.3 mm height. Single transistor configuration with NPN polarity.

This Nexperia Digital Transistor is suitable for industrial, automotive, and consumer electronic applications requiring reliable digital switching performance. Explore more electronic components and semiconductor devices in the EnvMart catalog for your design needs.
