DiodesZetex 120 V 20 A Switching Schottky Diode 4-Pin TO-220AB SDT20A120CT
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 16.51mm |
| Length | 10.66mm |
| Model | SDT20A120CT |
| Width | 4.82mm |
| Mount Type | Through Hole |
| Series | 20A TRENCH SCHOTTKY RECTIFIER |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-220AB |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | FBI |
| Pin Count | 4 |
| Maximum Continuous Forward Current If | 20A |
| Peak Reverse Repetitive Voltage Vrrm | 120V |
| Diode Configuration | 2x Common Cathode Pair |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 20mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 150A |
| Maximum Forward Voltage Vf | 790mV |
Key Features
- The diode features a 2x common cathode pair configuration ensuring efficient switching performance.
- Maximum forward voltage drop is 790mV, minimizing power losses.
- Peak non-repetitive forward surge current is rated at 150 A for transient protection.
- Capable of operation in temperatures ranging from -55°C to 150°C, supporting industrial environments.
- Compact dimensions of 16.51mm height, 10.66mm length, and 4.82mm width optimize PCB space.
- The rectifier series employs 20A trench Schottky technology for low forward voltage and high reliability.
- The package is standardized as TO-220AB, facilitating easy integration into designs.
- Pin count is 4, conforming to common cathode diode configurations.
Product Description
DiodesZetex SDT20A120CT is a high-performance switching Schottky diode with a peak reverse repetitive voltage of 120 V and a maximum continuous forward current of 20 A. Packaged in the TO-220AB through-hole mounting format with 4 pins, it offers efficient power rectification in compact electronic circuits.
This device features a 2x common cathode pair diode configuration with a maximum forward voltage of 790mV, enabling low conduction losses and enhanced efficiency for power conversion systems. It supports peak non-repetitive forward surge currents up to 150 A, protecting against transient spikes during startup or fault conditions.
The diode operates reliably within a wide temperature range from -55°C to 150°C, suitable for demanding industrial, automotive, and power electronics applications. Its physical dimensions of 16.51mm height, 10.66mm length, and 4.82mm width facilitate compact PCB designs.
The diode series uses advanced 20A trench Schottky technology providing low forward voltage drop and high thermal stability, making it ideal for switching power supplies, DC-DC converters, solar inverters, and other power management units.
The diode features a 2x common cathode pair configuration ensuring efficient switching performance. Maximum forward voltage drop is 790mV, minimizing power losses. Peak non-repetitive forward surge current is rated at 150 A for transient protection.
Capable of operation in temperatures ranging from -55°C to 150°C, supporting industrial environments. Compact dimensions of 16.51mm height, 10.66mm length, and 4.82mm width optimize PCB space. The rectifier series employs 20A trench Schottky technology for low forward voltage and high reliability.
The package is standardized as TO-220AB, facilitating easy integration into designs. Pin count is 4, conforming to common cathode diode configurations. Peak reverse current is limited to 20mA ensuring stable diode operation.
This diode is designed as a switching rectifier suitable for power management applications.
This diode is ideal for use in industrial automation, consumer electronics, power supply regulation, electrical equipment, and automotive power systems requiring efficient and reliable diode switching.
Explore more semiconductor and diode products on EnvMart for your electronic component needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum reverse repetitive voltage for this diode is 120 V.
This model has a maximum continuous forward current rating of 20 A.
The peak non-repetitive forward surge current is rated at 150 A.
The diode has dimensions of 16.51 mm in height, 10.66 mm in length, and 4.82 mm in width.
It is packaged in a TO-220AB format, suitable for through-hole mounting.
This diode operates reliably within a temperature range from -55°C to 150°C.
The maximum forward voltage drop is 790 mV, minimizing power losses during operation.
This model features a pin count of 4, conforming to a common cathode diode configuration.
It utilizes a 2x common cathode pair configuration for efficient switching performance.
The diode is compliant with FBI standards/approvals.
This diode is classified as a switching rectifier, suitable for power management applications.
The peak reverse current is limited to 20 mA, ensuring stable operation.
