ASSMANN WSW D-Sub Connector 15 Way Right Angle 2.54 mm Pitch Cable IDC Termination A-DFF 15LPIII/Z

Free Delivery in India | Lowest Global Shipping Charges

ASSMANN WSW D-Sub Connector 15 Way Right Angle 2.54 mm Pitch Cable IDC Termination A-DFF 15LPIII/Z

Name: ASSMANN WSW D-Sub Connector 15 Way Right Angle 2.54 mm Pitch Cable IDC Termination A-DFF 15LPIII/Z
Brand: ASSMANN WSW
SKU: 208260
Price: 1.95 USD
Availability: InStock



Category D-Sub Connector Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	250V
Brand	ASSMANN WSW
Orientation	Right Angle
Current	1A
Model	A-DFF 15LPIII/Z
Mount Type	Cable
Housing Material	Steel
Contact Material	Brass
Series	A-DFF
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Gold over Nickel
Number of Contacts	15
Contact Gender	Female
Connector Gender	Male/Female
Connector Type D	D-Sub

Key Features

The connector features 15 contacts rated for 1 amp current capacity.
It has a right angle orientation for compact PCB space utilization.
The cable mount type is suitable for IDC termination ensuring efficient cable connection.
Constructed with steel housing and brass contacts plated with gold over nickel for durability and corrosion resistance.
Operates safely within a voltage rating of 250V and temperature range of -55°C to 105°C.
The pitch between contacts is 2.54 mm, suitable for standard D-sub applications.
Compatible with male/female connector gender configuration for versatile mating options.
This product is manufactured in China and belongs to the A-DFF series connectors.

Product Description

ASSMANN WSW A-DFF 15LPIII/Z is a high-quality 15 Way D-Sub Connector designed for cable IDC termination with a 2.54 mm pitch and right angle orientation. This connector ensures robust electrical connections essential in electronic components, power connectors, and communication equipment.

Designed with steel housing and brass contacts plated with gold over nickel, it offers excellent durability and resistant performance against environmental factors and mechanical wear. The connector supports a current rating of 1 amp and a voltage up to 250 volts, making it suitable for various industrial and electronic applications.

The temperature operating range is from -55°C to 105°C, allowing reliable use in demanding environments. Its male/female contact gender configuration and right angle orientation facilitate efficient PCB layouts and integration in cable assemblies.

This product is part of the A-DFF series and comes manufactured from China, adhering to stringent quality standards. The IDC termination type allows for quick and secure cable connections, enhancing assembly efficiency in manufacturing processes.

The connector features 15 contacts rated for 1 amp current capacity. It has a right angle orientation for compact PCB space utilization. The cable mount type is suitable for IDC termination ensuring efficient cable connection.

Constructed with steel housing and brass contacts plated with gold over nickel for durability and corrosion resistance. Operates safely within a voltage rating of 250V and temperature range of -55°C to 105°C. The pitch between contacts is 2.54 mm, suitable for standard D-sub applications.

Compatible with male/female connector gender configuration for versatile mating options. This product is manufactured in China and belongs to the A-DFF series connectors.

This D-Sub Connector is ideal for applications in industrial automation, electronic manufacturing, power supply interfaces, and other commercial equipment requiring reliable cable connections. EnvMart offers this premium grade connector as part of its extensive electrical component portfolio.
