ASSMANN WSW 1.27 mm Pitch 32 Way DIP Through Hole PLCC IC Socket A-CCS 032-Z-T
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 100V |
| Brand | ASSMANN WSW |
| Orientation | Straight |
| Current | 1A |
| Model | A-CCS 032-Z-T |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | A-CCS 03 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 4 |
| Pitch | 1.27mm |
| Standards/Approvals | RoHS |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 32 |
| IC Socket Type | PLCC Socket |
| Device Mount Type | Through Hole |
Key Features
- Current rating of 1A ensures safe conduction for moderate power circuits.
- Featuring 32 contacts arranged in 4 rows for compact PCB mounting.
- Constructed with phosphor bronze contacts for durability and low resistance.
- Contacts plated with tin over nickel for corrosion resistance and long life.
- Through hole mounting type provides secure and stable mechanical attachment.
- Operating temperature range from -40°C to 105°C supports diverse environmental conditions.
- Housing made of Polybutylene Terephthalate for robust insulation and heat resistance.
- Complies with RoHS standards ensuring environmental safety and reduced hazardous substances.
Product Description
ASSMANN WSW A-CCS 032-Z-T 32 Way DIP Through Hole PLCC IC Socket is a precision connector designed for through-hole mounting on printed circuit boards (PCBs). It features a pitch of 1.27 mm, accommodating 32 contacts in a 4-row configuration, making it suitable for compact electronic assemblies requiring reliable IC socket connections.
The contacts are made from phosphor bronze, which provides mechanical strength and excellent electrical conductivity. These contacts are plated with a tin over nickel finish that enhances corrosion resistance and ensures long-term durability in various environmental conditions. The housing is manufactured from Polybutylene Terephthalate, a high-performance plastic known for its thermal stability and insulation properties.
This IC socket supports current up to 1A and voltage ratings up to 100V, suitable for many electronic circuits in industrial, laboratory, and manufacturing environments. Its operating temperature range from -40°C to 105°C ensures dependable performance even in extreme ambient conditions.
Compliant with RoHS standards, the socket is environmentally friendly, reducing harmful substances in electronic equipment. It is part of the trusted A-CCS 03 series by ASSMANN WSW, known for quality and precision in connector components.
The through hole mount type provides a secure mechanical connection to PCBs, ideal for applications requiring durable and removable IC interfaces for testing, repair, or prototyping.
Current rating 1A for moderate power signal connections. 32 contacts in 4 rows with 1.27 mm pitch spacing. Phosphor bronze contact material for durability. Tin over nickel plating to prevent corrosion. Through hole mounting ensures mechanical integrity.
Operating temperature range -40°C to 105°C. Rated voltage of 100V for versatile use. Housing made from Polybutylene Terephthalate for heat resistance. RoHS compliant for environmental safety. Series A-CCS 03 assures product consistency.
This IC socket is particularly suitable for industrial electronics, laboratory equipment, manufacturing machines, and other electronic systems requiring reliable IC interface connectors. Its robust design complements environments needing steady electrical and mechanical performance.
Explore more IC Socket solutions and accessories at EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this model is 1A, which ensures safe conduction for moderate power circuits.
This IC socket has a voltage rating of 100V, making it suitable for various electronic circuits.
The contacts are made from phosphor bronze, providing mechanical strength and excellent electrical conductivity.
The operating temperature range is from -40°C to 105°C, allowing it to perform reliably in diverse environmental conditions.
It features 32 contacts arranged in 4 rows, designed for compact PCB mounting.
This model uses through hole mounting, providing a secure and stable mechanical attachment to printed circuit boards.
The pitch size is 1.27 mm, accommodating the arrangement of the contacts in a compact manner.
The housing is made of Polybutylene Terephthalate, known for its robust insulation and heat resistance properties.
Yes, it complies with RoHS standards, ensuring reduced hazardous substances in electronic equipment.
The contacts are plated with tin over nickel, which enhances corrosion resistance and ensures long-term durability.
This model is part of the A-CCS 03 series by ASSMANN WSW, known for quality and precision in connector components.
The termination type for this model is solder, suitable for permanent connections on PCBs.
