Winslow 1.27 mm Pitch 20 Way Through Hole PLCC IC Socket WPLCC020-ST1RC

Winslow WPLCC020-ST1RC 1.27 mm Pitch 20 Way Through Hole PLCC IC Socket is engineered for demanding industrial and electronic applications requiring reliable integrated circuit connections. The socket features a through-hole mount type for robust attachment to printed circuit boards and excellent mechanical stability.

Constructed with phosphor bronze contacts plated with tin over copper, it provides outstanding electrical conductivity and corrosion resistance. Its 1A current rating and voltage ratings of 100 Vac rms and 150 Vdc make it suitable for various electronic designs and prototyping needs.

The socket accommodates 20 contacts spaced at a pitch of 1.27 mm (0.1 inch) to comply with JEDEC PLCC standards, ensuring compatibility with many chip carriers. Its low profile form factor, only 4.5 mm in height, allows for compact PCB layouts where space saving is critical.

Designed with a window for solder joint inspection and standoffs for easy PCB cleaning, this socket facilitates quality assurance and maintenance in production environments. Its operating temperature range of -55°C to 105°C guarantees reliable performance under harsh environmental conditions.

The housing material comprises fibreglass reinforced polyphenylene sulphide, providing excellent electrical insulation and mechanical durability. Typical mechanical life of the socket is 100 mating cycles, supporting multiple insertions and removals of ICs during testing or replacement.

Phosphor bronze contacts plated with tin over copper provide durable and efficient electrical connections. Through-hole mounting ensures firm PCB attachment and mechanical stability. 1.27 mm pitch spacing adheres to JEDEC standard PLCC package dimensions.

Voltage rating up to 150 Vdc suitable for various industrial and electronic circuits. Operating temperature range allows use in extreme environments from -55°C to 105°C. Low profile height of 4.5 mm complements compact PCB design requirements.

Window for solder joint inspection supports quality control in manufacturing processes. Fibreglass reinforced polyphenylene sulphide housing ensures robust insulation and mechanical strength. Standoffs facilitate PCB cleaning and maintenance.

Typical mechanical life is 100 cycles for repeated IC insertions.

This PLCC IC socket is ideally suited for industrial, manufacturing, electronics prototyping, and repair applications. It supports surface mount device mounting and offers reliable electrical and mechanical performance. Explore more IC Socket and connector solutions on EnvMart to complement your electronic component needs.
