Winslow Straight Through Hole Mount 2.54 mm Pitch IC Socket Adapter QFN to PGA WA13079DQAETRC
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Winslow |
| Orientation | Straight |
| Model | WA13079DQAETRC |
| Mount Type | Through Hole |
| Housing Material | Fibreglass |
| Contact Material | Brass |
| Pitch | 2.54mm |
| Connection Gender A | Female |
| Number of Contacts A | 56 |
| Connection Gender B | Male |
| Connection A | QFN |
| Connection B | PGA |
Key Features
- Enables the conversion of Quad-Flat No-Leads (QFN) packages to Pin Grid Array (PGA) format.
- Features a total of 56 female contacts on connection A and 56 male contacts on connection B.
- Constructed with brass contact material and fibreglass housing for durability.
- Designed for through hole mounting with a straight orientation on PCB.
- Manufactured in the United Kingdom, ensuring high quality standards.
- Lacks central ground pad to facilitate specific application needs.
- Adaptics reduce development costs by avoiding redesigns for alternative PCB packages.
Product Description
Winslow WA13079DQAETRC IC Socket Adapter is a precision adapter designed to facilitate the conversion from a Quad-Flat No-Leads (QFN) package to a Pin Grid Array (PGA) format. It is engineered for through hole mounting on printed circuit boards with a standardized pitch of 2.54 mm, providing reliable mechanical and electrical connections.
This adapter features 56 contacts arranged with female connections on the QFN side and corresponding 56 male contacts on the PGA side. The contacts are made of brass for excellent conductivity and rust resistance, while the housing is fabricated from fibreglass ensuring mechanical strength and thermal resilience.
The straight orientation socket mount is ideal for applications requiring adapters to bridge package footprint differences during prototyping or production runs without redesigning the PCB. It lacks a central ground pad, which suits designs where ground connection is handled separately or not required on the adapter itself.
Manufactured in the United Kingdom, the product adheres to rigorous standards for IC socket adapters in electronic development, testing, and manufacturing environments. Enables the conversion of Quad-Flat No-Leads (QFN) packages to Pin Grid Array (PGA) format.
Features 56 female contacts on connection A and 56 male contacts on connection B ensuring secure connections. Constructed using durable brass contacts and fibreglass housing for mechanical and electrical reliability. Through hole mount with straight orientation offers stable PCB integration.
Eliminates the need to redesign PCBs for alternative package adaptations, saving development costs. Suitable for laboratory, industrial electronics prototyping, and manufacturing workflows. This adapter is part of the Winslow Adaptics range to support flexible package style conversions, catering to evolving electronic assembly requirements.
Explore a wide selection of IC Socket Adapters and related electronic components at EnvMart for professional and industrial applications.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of the Winslow WA13079DQAETRC IC socket adapter is 2.54 mm.
This model features a total of 112 contacts, with 56 female contacts on the QFN connection A and 56 male contacts on the PGA connection B.
The contacts are made of brass, while the housing is constructed from fibreglass.
It is designed for through hole mounting on printed circuit boards.
The Winslow WA13079DQAETRC features a straight orientation for its socket mount.
This IC socket adapter is manufactured in the United Kingdom.
No, this model lacks a central ground pad, which may be suitable for designs where ground connection is handled separately.
It is suitable for laboratory, industrial electronics prototyping, and manufacturing workflows.
It eliminates the need to redesign PCBs for alternative package adaptations, saving development time and resources.
Connection A has female contacts and Connection B has male contacts.
The model number of this adapter is WA13079DQAETRC.
